1.产 品 资 料 介 绍：

SOI-200-ID-120操作面板产品应用领域

SOI-200-ID-120操作面板作为工业级人机交互控制单元，具备8个可编程功能键、NEMA 4/12/13及IP65高防护等级，支持PLC寄存器直接访问与报警生成功能，适配恶劣工业环境下的设备操控与数据监测需求，无需复杂编程即可实现快速集成，广泛应用于工业自动化、特种制造、新能源等领域，核心应用场景如下：

1. 工业自动化控制领域：适配PLC（可编程逻辑控制器）、变频器、伺服系统等工业控制核心设备，为其提供稳定的直流供电，保障自动化生产线、智能仓储设备、工业机器人等系统的连续精准运行，可耐受工业现场的电压波动、电磁干扰等复杂环境。

2. 半导体与SOI器件制造领域：应用于SOI（绝缘体上硅）器件生产线、半导体封装测试设备，通过精准的参数显示与输入功能，实现工艺参数（如温度、压力）的实时监控与调节。支持直接访问PLC数据寄存器，方便技术人员进行系统调试与故障诊断，其抗干扰特性可适配半导体洁净车间的高精度生产需求，保障SOI器件制造过程的稳定性。

3. 新能源汽车制造与动力控制领域：适配新能源汽车电池组装线、DriveONE多合一电驱动系统测试平台，作为现场操作与数据监测终端。可实时显示电池电压、电流、温度等关键参数，通过功能键实现测试流程启停与模式切换，具备安全权限分级功能，防止误操作。IP65防护等级可耐受生产现场的水汽与轻微冲击，保障测试与生产过程的安全性。

4. 特种工业设备操控领域：用于矿山机械、化工反应釜等特种设备，凭借NEMA 4/12/13防护等级与UL Class 1 Div 2认证，可在高粉尘、高湿度及易燃易爆环境下稳定工作。通过自定义菜单与功能键，实现设备运行状态监控、参数调节及紧急停机控制，支持联动报警系统，当设备参数超出安全范围时及时发出声光预警，保障作业安全。

5. 机器人工作站与仓储物流领域：适配工业机器人分拣工作站、智能仓储传送带系统，作为现场操作终端实现机器人点位调用、任务切换及运行状态监测。通过可编程功能键快速触发机器人复位、急停等常用操作，实时显示仓储物料数量与传送带运行速度，支持与PLC系统无缝协同，提升物流分拣与仓储管理的效率。

SOI-200-ID-120操作面板 英文资料：

Application Fields of SOI-200-ID-120 Operation Panel Product

The SOI-200-ID-120 operation panel, as an industrial grade human-machine interaction control unit, has 8 programmable function keys, NEMA 4/12/13 and IP65 high protection level. It supports direct access to PLC registers and alarm generation functions, and is suitable for equipment control and data monitoring needs in harsh industrial environments. It can be quickly integrated without complex programming and is widely used in industrial automation, special manufacturing, new energy and other fields. The core application scenarios are as follows:

1. In the field of industrial automation control, it is suitable for industrial control core equipment such as PLC (Programmable Logic Controller), frequency converter, servo system, etc., providing stable DC power supply to ensure the continuous and accurate operation of automated production lines, intelligent warehousing equipment, industrial robots and other systems. It can withstand complex environments such as voltage fluctuations and electromagnetic interference in industrial sites.

2. In the field of semiconductor and SOI device manufacturing: applied to SOI (silicon on insulator) device production lines and semiconductor packaging testing equipment, real-time monitoring and adjustment of process parameters (such as temperature and pressure) are achieved through precise parameter display and input functions. Support direct access to PLC data registers, facilitating system debugging and fault diagnosis for technicians. Its anti-interference characteristics can adapt to the high-precision production needs of semiconductor cleanrooms, ensuring the stability of SOI device manufacturing processes.

3. In the field of new energy vehicle manufacturing and power control, it is suitable for new energy vehicle battery assembly lines and DriveONE multi in one electric drive system testing platforms, serving as on-site operation and data monitoring terminals. Real time display of key parameters such as battery voltage, current, temperature, etc., enabling start stop and mode switching of the testing process through function keys, with safety permission grading function to prevent misoperation. The IP65 protection level can withstand water vapor and slight impacts on the production site, ensuring the safety of testing and production processes.

4. Special industrial equipment control field: used for special equipment such as mining machinery and chemical reaction vessels. With NEMA 4/12/13 protection level and UL Class 1 Div 2 certification, it can work stably in high dust, high humidity, and flammable and explosive environments. By customizing menus and function keys, device operation status monitoring, parameter adjustment, and emergency stop control can be achieved. It supports a linked alarm system, which can issue sound and light warnings in a timely manner when device parameters exceed the safe range, ensuring job safety.

5. Robot workstations and warehousing logistics field: adapted to industrial robot sorting workstations and intelligent warehousing conveyor systems, serving as on-site operation terminals to achieve robot point calling, task switching, and operation status monitoring. By using programmable function keys to quickly trigger common operations such as robot reset and emergency stop, the real-time display of the quantity of stored materials and the running speed of the conveyor belt supports seamless collaboration with the PLC system, improving the efficiency of logistics sorting and warehouse management.

SOI-200-ID-120操作面板 产品展示

产品视频
