RMX-800绝缘监测仪

RMX-800绝缘监测仪

1.产 品 资 料 介 绍：

RMX-800绝缘监测仪产品特点

1. 支持直流不接地系统正、负极对地绝缘电阻精准监测，测量量程宽，覆盖0.01MΩ至2000MΩ，满足多场景监测需求。

2. 具备多重电压监测功能，可实时采集系统正负极间电压、正负极对地电压，保障电压状态全面管控。

3. 采用高精度监测技术，绝缘电阻测量精度高，误差控制在较小范围，为故障判断提供可靠数据支撑。

4. 搭载多级预警报警机制，支持绝缘电阻、过压、欠压等多重异常报警，预警与报警阈值可独立调节。

5. 具备PE/KE断线报警功能，实时监测接地线路连接状态，杜绝接地失效带来的安全风险。

6. 配备128*64点阵液晶显示屏，清晰呈现绝缘电阻、电压等关键参数，操作界面直观易懂。

7. 设有运行、通讯、故障、预警、报警多色LED指示灯，快速反馈设备工作状态，便于现场查看。

8. 支持故障定位功能，可精准显示正负极对地关键参数，助力工作人员快速锁定绝缘故障位置。

9. 内置事件记录功能，可存储50条以上报警事件，包含故障类型、数值及时间，便于历史追溯与排查。

10. 配置RS485通讯接口，兼容Modbus-RTU协议，实现与上位机远程数据交互及参数配置。

11. 具备数字量输入输出接口，支持自检、复位、状态切换等功能，可灵活适配不同控制场景。

12. 工业级宽温设计，支持-25℃至+70℃工作温度，抗潮湿、抗振动，适应恶劣工业工况。

13. 采用标准35mm DIN导轨安装，插拔式端子接线，安装与后期维护便捷高效，节省人力成本。

14. 集成过压保护、反接保护等多重防护机制，全面保障设备自身及监测系统安全稳定运行。

15. 广泛应用于变电站直流屏、新能源充电桩、UPS系统、工业直流电机等领域，筑牢电气系统安全防线。

RMX-800绝缘监测仪 英文资料：

RMX-800 Insulation Monitoring Instrument Product Features

1. Support precise monitoring of positive and negative insulation resistance to ground in DC ungrounded systems, with a wide measurement range covering 0.01M Ω to 2000M Ω, meeting the monitoring needs of multiple scenarios.

2. Equipped with multiple voltage monitoring functions, it can real-time collect the voltage between the positive and negative poles of the system, as well as the voltage between the positive and negative poles to ground, ensuring comprehensive control of voltage status.

3. Adopting high-precision monitoring technology, the measurement accuracy of insulation resistance is high, and the error is controlled within a small range, providing reliable data support for fault diagnosis.

4. Equipped with a multi-level warning and alarm mechanism, it supports multiple abnormal alarms such as insulation resistance, overvoltage, undervoltage, etc. The warning and alarm thresholds can be independently adjusted.

5. Equipped with PE/KE disconnection alarm function, real-time monitoring of grounding line connection status, to eliminate safety risks caused by grounding failure.

6. Equipped with a 128 * 64 dot matrix LCD display screen, it clearly presents key parameters such as insulation resistance and voltage, and the operation interface is intuitive and easy to understand.

7. It is equipped with multi-color LED indicator lights for operation, communication, fault, warning, and alarm, which can quickly feedback the working status of the equipment and facilitate on-site inspection.

8. Support fault location function, accurately display key parameters of positive and negative poles to ground, and assist staff in quickly locking the location of insulation faults.

9. Built in event recording function, can store more than 50 alarm events, including fault types, values, and times, for easy historical traceability and troubleshooting.

10. Configure RS485 communication interface, compatible with Modbus RTU protocol, to achieve remote data exchange and parameter configuration with the upper computer.

11. It has digital input and output interfaces, supports self checking, reset, status switching and other functions, and can flexibly adapt to different control scenarios.

12. Industrial grade wide temperature design, supporting working temperatures from -25 ℃ to+70 ℃, resistant to moisture and vibration, suitable for harsh industrial conditions.

13. Adopting standard 35mm DIN rail installation, plug-in terminal wiring, easy and efficient installation and maintenance, saving labor costs.

14. Integrate multiple protection mechanisms such as overvoltage protection and reverse connection protection to comprehensively ensure the safe and stable operation of the equipment itself and monitoring system.

15. Widely used in fields such as substation DC screens, new energy charging piles, UPS systems, industrial DC motors, etc., to build a strong defense line for electrical system safety.

RMX-800绝缘监测仪 产品展示

产品视频
