1.产 品 资 料 介 绍：

6T0269A执行器总线模块产品特点（15条）

6T0269A是工业级执行器总线控制核心模块，专为阀门、风门等执行机构的总线化控制设计，适配石油化工、电力冶金等严苛场景，核心特点如下：

1. 多总线协议兼容

原生支持PROFIBUS-DP、Modbus-RTU协议，可选配以太网/IP扩展模块，无缝接入工业控制系统，实现指令与数据双向传输。

2. 高精度位置控制

内置16位高精度位置反馈采集模块，定位精度±0.1%FS，支持比例调节与定位控制，响应速度≤10ms，保障执行机构精准动作。

3. 宽电压供电适配

支持AC220V±10%或DC24V宽电压供电，兼容50/60Hz频率，适应工业电网波动，功耗低至8W，节能且运行稳定。

4. 全面状态监测

实时监测执行器位置、力矩、温度及电源状态，可采集电流、电压等运行参数，为预测性维护提供数据支撑。

5. 多重安全保护

具备过流、过温、过载、欠压保护功能，支持紧急停机与故障复位，内置浪涌抑制电路，防止瞬时高压损坏模块。

6. 强抗干扰性能

采用光电隔离与EMC滤波技术，信号与电源隔离电压达2500VAC，通过EN55022电磁兼容认证，抵御工业环境干扰。

7. 灵活参数配置

支持通过总线远程配置参数，也可通过本地拨码开关快速调试，内置参数记忆功能，断电后参数不丢失。

8. 故障自诊断与报警

自动识别模块故障、总线异常及执行器故障，通过指示灯与总线信号双重报警，记录故障代码便于快速排查。

9. 宽温环境适配

工作温度范围-25℃~+70℃，存储温度-40℃~+85℃，湿度≤95%（无凝露），适配高温、严寒等复杂工况。

10. 模块化结构设计

采用插拔式模块化设计，体积紧凑，适配标准DIN导轨安装，便于快速更换与维护，节省机柜空间。

11. 多信号输出输入

配备4-20mA模拟量输出/输入接口，支持开关量信号联动，可直接驱动执行器电机，适配不同类型执行机构。

12. 高可靠性运行

选用工业级元器件，经过严苛环境测试，平均无故障时间（MTBF）超10万小时，保障长期稳定运行。

13. 国际合规认证

符合IEC 61131-2工业控制标准，通过CE、UL、RoHS认证，适配国内外不同行业合规要求。

14. 支持冗余备份

支持总线冗余与双电源备份功能，故障切换时间≤50ms，确保关键控制回路不中断，提升系统可靠性。

15. 多场景适配性

兼容角行程、直行程等多种执行器，广泛应用于阀门控制、风门调节、泵体启停等场景，适配石油化工、电力、水处理等行业。

6T0269A执行器总线模块 英文资料：

6T0269A actuator bus module product features (15 items)

6T0269A is an industrial grade actuator bus control core module designed specifically for bus based control of actuators such as valves and dampers, suitable for harsh scenarios such as petrochemicals and electric metallurgy. Its core features are as follows:

1. Multi bus protocol compatibility

Native support for PROFIBUS-DP and Modbus RTU protocols, optional Ethernet/IP expansion module, seamless integration into industrial control systems, achieving bidirectional transmission of instructions and data.

2. High precision position control

Built in 16 bit high-precision position feedback acquisition module, positioning accuracy ± 0.1% FS, supports proportional adjustment and positioning control, response speed ≤ 10ms, ensuring precise action of the actuator.

3. Wide voltage power supply adaptation

Supports AC220V ± 10% or DC24V wide voltage supply, compatible with 50/60Hz frequency, adaptable to industrial power grid fluctuations, with power consumption as low as 8W, energy-saving and stable operation.

4. Comprehensive status monitoring

Real time monitoring of actuator position, torque, temperature, and power status, capable of collecting operational parameters such as current and voltage, providing data support for predictive maintenance.

5. Multiple security protections

Equipped with overcurrent, overtemperature, overload, and undervoltage protection functions, supporting emergency shutdown and fault reset, and built-in surge suppression circuit to prevent module damage from instantaneous high voltage.

6. Strong anti-interference performance

Adopting optoelectronic isolation and EMC filtering technology, the signal and power isolation voltage reaches 2500VAC, and has passed EN55022 electromagnetic compatibility certification to resist industrial environmental interference.

7. Flexible parameter configuration

Supports remote configuration of parameters through the bus, and can also be quickly debugged through local dip switches. Built in parameter memory function ensures that parameters are not lost after power failure.

8. Fault self diagnosis and alarm

Automatically identify module faults, bus anomalies, and actuator faults, and provide dual alarms through indicator lights and bus signals to record fault codes for quick troubleshooting.

9. Wide temperature environment adaptation

Working temperature range -25 ℃~+70 ℃, storage temperature -40 ℃~+85 ℃, humidity ≤ 95% (no condensation), suitable for complex working conditions such as high temperature and severe cold.

10. Modular structure design

Adopting a plug-in modular design, it is compact in size and compatible with standard DIN rail installation, making it easy to quickly ｒｅｐｌａｃｅ and maintain, saving cabinet space.

11. Multiple signal output and input

Equipped with 4-20mA analog output/input interface, supporting switch signal linkage, can directly drive actuator motors, and adapt to different types of actuators.

12. High reliability operation

Industrial grade components are selected and subjected to rigorous environmental testing, with an average time between failures (MTBF) exceeding 100000 hours, ensuring long-term stable operation.

13. International Compliance Certification

Compliant with the IEC 61131-2 industrial control standard, certified by CE, UL, and RoHS, and adaptable to compliance requirements of different industries both domestically and internationally.

14. Support redundant backup

Support bus redundancy and dual power backup function, with a fault switching time of ≤ 50ms, ensuring that critical control circuits are not interrupted and improving system reliability.
