REX010 HESG324426R1地面故障保护装置

REX010 HESG324426R1地面故障保护装置

1.产 品 资 料 介 绍：

1. 品牌型号：ABB（瑞士）REX010，物料号 HESG324426R1，为发电机定子接地故障注入式保护单元。
2. 核心定位：专用于中高压发电机定子 100% 接地故障保护，需配合注入变压器 REX011 与 REG216/316 继电器使用。
3. 工作原理：采用注入式检测，向定子回路注入低频信号，精准检测包括中性点在内的全绕组接地故障。
4. 供电规格：辅助电源为直流 36–312VDC，适配电站蓄电池系统，无需额外交流供电。
5. 电压适配：一次侧最高监测电压可达3200VDC，覆盖主流中高压发电机系统。
6. 频率范围：适配 50/60Hz 工频系统，兼容全球电网频率标准。
7. 保护范围：实现100% 定子绕组接地故障保护，含中性点区域，无保护盲区。
8. 双点检测：可识别保护区内两个独立接地点，提升复杂工况下故障检出能力。
9. 自检功能：持续监控注入电压、信号幅度 / 频率及接地系统状态，异常自动报警。
10. 系统兼容：与 ABB REG216、REG316 保护继电器无缝配合，构成完整定子 / 转子接地保护方案。
11. 安装形式：模块化设计，适配开关柜嵌入式安装，结构紧凑。
12. 环境适应：工作温度 - 20℃~+55℃，存储温度 - 40℃~+85℃，满足电站严苛环境。
13. 防护等级：外壳防护IP65，防尘防水，适用于工业与电站现场。
14. 重量尺寸：约 7.35kg，尺寸约 25.4×20.3×1.3cm，便于机柜布置。
15. 应用场景：火力 / 水力 / 核电站、工业自备电站、船舶电站等中高压发电机系统。

REX010 HESG324426R1地面故障保护装置 英文资料：

Brand and model: ABB (Switzerland) REX010, material number HESG324426R1, is an injection type protection unit for generator stator grounding faults.

Core positioning: Dedicated to 100% grounding fault protection of stator in medium and high voltage generators, it needs to be used in conjunction with REX011 injection transformer and REG216/316 relay.

Working principle: Using injection detection, low-frequency signals are injected into the stator circuit to accurately detect all winding grounding faults, including the neutral point.

Power supply specifications: The auxiliary power supply is DC 36-312VDC, compatible with the power station battery system, and does not require additional AC power supply.

Voltage adaptation: The maximum monitoring voltage on the primary side can reach 3200VDC, covering mainstream medium and high voltage generator systems.

Frequency range: Suitable for 50/60Hz power frequency systems and compatible with global grid frequency standards.

Protection range: Achieve 100% stator winding grounding fault protection, including neutral point area, without protection blind spots.

Double point detection: It can identify two independent grounding points within the protected area, improving the ability to detect faults under complex working conditions.

Self check function: continuously monitor the injected voltage, signal amplitude/frequency, and grounding system status, and automatically alarm for abnormalities.

System compatibility: seamlessly cooperate with ABB REG216 and REG316 protective relays to form a complete stator/rotor grounding protection scheme.

Installation form: Modular design, suitable for embedded installation in switchgear, compact structure.

Environmental adaptation: working temperature -20 ℃~+55 ℃, storage temperature -40 ℃~+85 ℃, meeting the harsh environment of power plants.

Protection level: IP65 shell protection, dustproof and waterproof, suitable for industrial and power plant sites.

Weight and dimensions: approximately 7.35kg, dimensions of approximately 25.4 × 20.3 × 1.3cm, convenient for cabinet layout.

Application scenarios: High voltage generator systems such as thermal/hydraulic/nuclear power plants, industrial self owned power plants, and ship power plants.

In summary, REX010 HESG324426R1 is an injection type ground fault protection core unit designed by ABB specifically for medium and high voltage generators. With 100% full winding protection, dual point detection, wide voltage DC power supply, and high protection as its core advantages, it is a key equipment to ensure the safe operation of large generators.
