A06B-6077-H106伺服驱动器

1.产 品 资 料 介 绍：

FANUC A06B-6077-H106 伺服驱动器（纯文字版）

1. 类型定位：α 系列伺服电源 / 主轴驱动模块（PSM-5.5）
2. 输入规格：三相 200-230V AC，50/60Hz，额定电流 26A（200V 时）
3. 输出规格：直流 283-325V，额定功率 6.8kW，适配中大功率伺服系统
4. 控制核心：内置 DSP+HRV3 高响应矢量控制，动态响应快、定位精度高
5. 通信接口：FSSB 高速串行伺服总线，单光纤与 CNC（0i/16i/18i/21i/30i）通信
6. 适配电机：FANUC α/αi 系列伺服电机、主轴电机
7. 冷却方式：强制风冷（内置风扇 + 外置散热器），散热高效
8. 保护功能：过流、过压、欠压、过热、短路、风扇故障、母线异常等多重保护
9. 常见报警：AL-01（过流）、AL-02（风扇停）、AL-04（母线欠压）、AL-06（输入异常）
10. 结构设计：标准机架插卡式，宽 90mm，金属屏蔽外壳，抗干扰强
11. 环境参数：工作温度 - 20℃~+60℃，适应工业恶劣现场
12. 应用场景：数控加工中心、数控车床、铣床、FANUC 机器人、自动化产线
13. 品质特性：日本原厂制造，工业级可靠性，长寿命、低故障率

A06B-6077-H106伺服驱动器  产品英文

FANUC A06B-6077-H06 Servo Drive (Text Version)

A06B-6077-H106 (also known as PSM-5.5) is a servo power module/spindle driver from FANUC's alpha series in Japan. It provides high-voltage DC bus and servo power for CNC systems, with a focus on high power, high stability, and digital intelligent control.

Type positioning: Alpha series servo power supply/spindle drive module (PSM-5.5)

Input specifications: three-phase 200-230V AC, 50/60Hz, rated current 26A (at 200V)

Output specifications: DC 283-325V, rated power 6.8kW, suitable for medium to high power servo systems

Control core: Built in DSP+HRV3 high response vector control, fast dynamic response, high positioning accuracy

Communication interface: FSSB high-speed serial servo bus, single fiber communication with CNC (0i/16i/18i/21i/30i)

Compatible motors: FANUC α/α i series servo motors, spindle motors

Cooling method: forced air cooling (internal fan+external radiator), efficient heat dissipation

Protection functions: multiple protections such as overcurrent, overvoltage, undervoltage, overheating, short circuit, fan failure, bus abnormality, etc

Common alarms: AL-01 (overcurrent), AL-02 (fan stop), AL-04 (bus undervoltage), AL-06 (input abnormality)

Structural design: Standard rack plug-in card, 90mm wide, metal shielding shell, strong anti-interference

Environmental parameters: Operating temperature -20 ℃~+60 ℃, suitable for harsh industrial environments

Application scenarios: CNC machining centers, CNC lathes, milling machines, FANUC robots, automated production lines

Quality characteristics: Made in Japan, industrial grade reliability, long lifespan, low failure rate

The overall servo power/drive core is high-power, highly reliable, and digital, and is a key component for stable power and precision control in FANUC CNC systems.

A06B-6077-H106伺服驱动器    产品展示
