IDEC PF3S-T32K输出模块

IDEC PF3S-T32K输出模块

1.产 品 资 料 介 绍：

1. 适配 IDEC FA-3S 系列 PLC，属于专用数字量输出扩展模块
2. 提供 32 路独立晶体管输出点，满足多路负载同时控制需求
3. 输出类型为 NPN 漏型，适配 DC12~24V 直流负载驱动
4. 单路最大输出电流 240mA，可直接驱动继电器、指示灯、小型电磁阀
5. 每路输出配备独立 LED 状态指示灯，实时显示通断状态
6. 输出电路与 PLC 内部光电隔离，有效抑制工业现场干扰
7. 支持高速响应，开关动作迅速，适配高频控制场景
8. 集成过流保护与反极性保护，降低模块与负载损坏风险
9. 采用标准 35mm 导轨安装，直接插接于 FA-3S 系列 PLC 扩展底板
10. 模块结构紧凑，尺寸小巧，节省控制柜安装空间
11. 工业级宽温设计，工作温度 - 10°C~+55°C，适应恶劣工况
12. 输出点分组隔离，减少单点故障对整体系统的影响
13. 支持带电插拔功能，维护时无需断电，提升设备运行效率
14. 广泛应用于自动化生产线、包装机械、机床控制、装配设备等领域

IDEC PF3S-T32K输出模块  产品英文

IDEC PF3S-T32K is a 32-bit digital output module dedicated to the FA-3S series PLC of Hequan. It adopts transistor leakage output and is designed specifically for multi-channel signal driving in industrial automation control systems. It has stable and reliable control performance, with the following specific characteristics:

Compatible with IDEC FA-3S series PLC, belonging to dedicated digital output expansion module

Provide 32 independent transistor output points to meet the simultaneous control requirements of multiple loads

Output type is NPN leakage type, suitable for DC12~24V DC load drive

The maximum output current of a single channel is 240mA, which can directly drive relays, indicator lights, and small solenoid valves

Each output is equipped with an independent LED status indicator, which displays the on/off status in real-time

The output circuit is isolated from the internal photoelectric of the PLC, effectively suppressing interference in the industrial field

Support high-speed response, quick switch action, suitable for high-frequency control scenarios

Integrated overcurrent protection and reverse polarity protection to reduce the risk of module and load damage

Installed using standard 35mm guide rails, directly plugged into the FA-3S series PLC expansion board

Compact module structure, small size, saving installation space for control cabinets

Industrial grade wide temperature design, working temperature -10 ° C~+55 ° C, suitable for harsh working conditions

Output point grouping isolation reduces the impact of single point failures on the overall system

Support live plug and unplug function, no need to power off during maintenance, improve equipment operation efficiency

Widely used in fields such as automated production lines, packaging machinery, machine tool control, assembly equipment, etc

IDEC PF3S-T32K输出模块  产品展示

产品视频
