INDRAMAT 109-0943-3801-05电源板单元

INDRAMAT 109-0943-3801-05电源板单元

1.产 品 资 料 介 绍：

1. 品牌归属博世力士乐 INDRAMAT，属于伺服驱动器核心电源与功率单元。
2. 官方定义为主轴放大模块（Spindle Amplifier Module），负责驱动伺服主轴电机。
3. 输入为三相 400V AC工业电网电压，适配标准工业供电系统。
4. 额定功率输出5kW，满足中功率伺服主轴的动力需求。
5. 额定输出电流15A，匹配伺服电机的稳定驱动与过载能力。
6. 输出频率范围0-400Hz，支持电机高速与低速精准调速。
7. 内置整流、滤波、稳压电路，将交流电转为伺服系统所需直流电。
8. 具备过压、过流、短路、过热多重保护，保障模块与电机安全。
9. 采用强制风冷（Forced Air）散热，确保高负载持续稳定运行。
10. 防护等级IP20，适配控制柜内安装，防尘防触保护。
11. 工作温度范围 **-20°C 至 + 50°C**，适应严苛工业环境。
12. 模块尺寸400×300×150mm，标准工业机柜安装规格。
13. 重量约15kg，结构坚固，适配工业振动工况。
14. 主要配套 INDRAMAT DKC 系列伺服驱动器，用于数控机床、自动化生产线。

109-0943-3801-05电源板单元  产品英文

109-0943-3801-05 is a servo drive power board/spindle amplification module of Bosch Rexroth's INDRAMAT series, providing core power conversion and power amplification for servo systems. Its specific features are as follows:

The brand belongs to Bosch Rexroth INDRAMAT and is a core power supply and power unit for servo drives.

Officially defined as the Spindle Amplifier Module, responsible for driving servo spindle motors.

The input is a three-phase 400V AC industrial power grid voltage, suitable for standard industrial power supply systems.

Rated power output of 5kW, meeting the power requirements of medium power servo spindles.

Rated output current of 15A, matched with stable driving and overload capacity of servo motor.

The output frequency range is 0-400Hz, supporting precise speed regulation of motors at high and low speeds.

Built in rectification, filtering, and voltage stabilization circuits convert AC power into DC power required by the servo system.

Equipped with multiple protections against overvoltage, overcurrent, short circuit, and overheating, ensuring the safety of modules and motors.

Adopting forced air cooling to ensure continuous and stable operation under high loads.

Protection level IP20, suitable for installation inside control cabinets, dust-proof and anti touch protection.

The working temperature range is * * -20 ° C to+50 ° C * *, suitable for harsh industrial environments.

Module size 400 × 300 × 150mm, standard industrial cabinet installation specifications.

Weighing approximately 15kg, the structure is sturdy and suitable for industrial vibration conditions.

Mainly equipped with INDRAMAT DKC series servo drives, used for CNC machine tools and automated production lines.

109-0943-3801-05电源板单元  产品展示
