1.产 品 资 料 介 绍：
- 品牌归属博世力士乐 INDRAMAT，属于 TDM 系列伺服驱动器的核心辅助板卡。
- 官方型号为RC8，定位为制动电阻控制与系统接口模块。
- 适配 INDRAMAT TDM 系列伺服控制器，负责制动电阻的投切与保护控制。
- 集成制动电阻切换电路，实现伺服电机快速制动与能量吸收。
- 内置热保护与过流检测，保障制动电阻与模块安全运行。
- 提供系统内部信号接口，实现与主控板的指令与状态交互。
- 采用欧式插卡式设计，直接插接于 TDM 系列驱动机架插槽。
- 工业级硬件设计，适应控制柜内高温、电磁干扰工况。
- 板载接线端子布局规范，安装与接线操作简便。
- 支持多轴制动电阻管理，适配中功率伺服系统制动需求。
- 具备自诊断功能，可反馈制动回路异常与故障代码。
- 结构紧凑，适配标准工业机柜安装，节省空间。
- 做工坚固，抗振动性能良好，符合工业使用标准。
- 可直接替换同型号故障板卡，系统兼容性强。
INDRAMAT 109-525-1252A接口模块 产品英文
INDRAMAT 109-525-1252A is an RC8 interface/braking resistor board specifically designed for the INDRAMAT TDM series servo drives under Bosch Rexroth. It is used for servo axis braking resistor management and system interface. Its specific features are as follows:
The brand belongs to Bosch Rexroth INDRAMAT, which is the core auxiliary board of TDM series servo drives.
The official model is RC8, positioned as a brake resistor control and system interface module.
Suitable for INDRAMAT TDM series servo controllers, responsible for switching and protection control of braking resistors.
Integrated braking resistor switching circuit to achieve fast braking and energy absorption of servo motors.
Built in thermal protection and overcurrent detection ensure the safe operation of braking resistors and modules.
Provide internal signal interfaces for the system to achieve instruction and status interaction with the main control board.
Adopting a European style card insertion design, it can be directly plugged into the TDM series driver rack slot.
Industrial grade hardware design, suitable for high temperature and electromagnetic interference conditions inside the control cabinet.
The layout of onboard wiring terminals is standardized, and installation and wiring operations are easy.
Support multi axis braking resistor management and adapt to the braking requirements of medium power servo systems.
Equipped with self diagnostic function, it can provide feedback on brake circuit abnormalities and fault codes.
Compact structure, suitable for standard industrial cabinet installation, saving space.
The workmanship is sturdy, the anti vibration performance is good, and it meets industrial use standards.
Can directly ｒｅｐｌａｃｅ faulty boards of the same model, with strong system compatibility.
INDRAMAT 109-525-1252A接口模块 产品展示
