1FT6064-1AF71-3AG1伺服电机

1FT6064-1AF71-3AG1伺服电机

1.产 品 资 料 介 绍：

1. 类型系列：西门子 1FT6 系列永磁同步伺服电机，工业级高精度型号。
2. 额定扭矩：9.5 Nm，连续输出稳定，动态响应快。
3. 额定转速：3000 rpm，最高转速支持过载运行。
4. 电气参数：三相 291V、5A，适配 400V 级伺服驱动系统。
5. 反馈系统：正余弦增量编码器（1Vss，2048 线），位置与速度反馈精准。
6. 冷却方式：自然冷却（自冷），无风扇，结构可靠。
7. 防护等级：IP65（整机），防尘防溅水，适应车间恶劣环境。
8. 安装形式：IM B5 法兰安装，支持 IM V1/IM V3 立式安装。
9. 机械设计：铸铝外壳，低振动、低噪音，重量约 12.5 kg。
10. 接口规格：轴向出线，标准动力 + 信号连接器，布线规范。
11. 绝缘等级：F 级，耐高温，长期运行稳定性强。
12. 适配驱动：完美兼容西门子 611、S120 等伺服驱动系统。
13. 应用领域：数控加工中心、机器人、精密机床、包装机械、印刷设备。
14. 寿命特性：稀土永磁转子，无退磁风险，轴承寿命长。
15. 市场状态：2015 年 10 月停产，目前以二手、翻新、备件为主。

1FT6064-1AF71-3AG1伺服电机 产品英文

1FT6064-1AF71-3AG1 is a Siemens SIMOTICS S series high-precision synchronous servo motor, originally manufactured in Germany, specializing in high dynamic and high positioning accuracy. It is used for high-end automation equipment such as CNC, robotics, and packaging machinery. Although it has been discontinued, it is still widely used in the market for maintenance and replacement.

Product Features

Type series: Siemens 1FT6 series permanent magnet synchronous servo motor, industrial grade high-precision model.

Rated torque: 9.5 Nm, stable continuous output, fast dynamic response.

Rated speed: 3000 rpm, maximum speed supports overload operation.

Electrical parameters: Three phase 291V, 5A, suitable for 400V servo drive system.

Feedback system: sine cosine incremental encoder (1vss, 2048 lines), precise position and velocity feedback.

Cooling method: Natural cooling (self cooling), fanless, reliable structure.

Protection level: IP65 (whole machine), dustproof and splash proof, suitable for harsh workshop environments.

Installation form: IM B5 flange installation, supports IM V1/IM V3 vertical installation.

Mechanical design: Cast aluminum casing, low vibration, low noise, weighing approximately 12.5 kg.

Interface specifications: axial outgoing line, standard power+signal connector, wiring specifications.

Insulation grade: F grade, high temperature resistance, strong long-term stability during operation.

Adaptive driver: Perfectly compatible with Siemens 611, S120 and other servo drive systems.

Application areas: CNC machining centers, robots, precision machine tools, packaging machinery, printing equipment.

Life characteristics: Rare earth permanent magnet rotor, no demagnetization risk, long bearing life.

Market Status: Discontinued production in October 2015, currently focused on second-hand, refurbished, and spare parts.

ending

This motor is centered around high dynamics, high precision, high reliability, and strong protection. It is a classic servo model from Siemens, widely used for high-end equipment maintenance and system upgrades, and stably adapts to various precision motion control scenarios.

1FT6064-1AF71-3AG1伺服电机  产品展示
