HP 44723A 控制器模块

1.产 品 资 料 介 绍：

HP 44723A 控制器模块

1. 32 通道高速数字输入输出控制
2. 支持 16 路输入、16 路输出独立配置
3. 单组通道切换速度高达 15 万次 / 秒
4. 支持外部触发与 16 位数字模式捕获
5. 输入可实现边沿触发与模式中断功能
6. 具备输出握手，保证控制信号稳定
7. 输入电压范围最大 ±24V DC
8. 集电极开路输出，最大负载 40mA
9. 兼容 TTL 电平，适配通用数字电路
10. 最小脉冲宽度可达 355ns
11. 低功耗设计，典型功耗 0.7W
12. 与 HP 3852A/3853A 主机完美兼容
13. 支持多模块级联扩展 I/O 数量
14. 工业级稳定，适合长期自动化控制

HP 44723A 控制器模块  产品英文

HP 44723A Controller Module

HP 44723A is a high-speed digital I/O controller module designed specifically for the HP 3852A/3853A data acquisition system.

32 channel high-speed digital input/output control

Supports independent configuration of 16 inputs and 16 outputs

Single channel switching speed of up to 150000 times per second

Support external triggering and 16 bit digital mode capture

Input can achieve edge triggering and mode interruption functions

Equipped with output handshake to ensure stable control signals

Maximum input voltage range ± 24V DC

Open collector output, maximum load 40mA

Compatible with TTL levels and compatible with general digital circuits

The minimum pulse width can reach 355ns

Low power design, typical power consumption 0.7W

Perfectly compatible with HP 3852A/3853A hosts

Support cascading expansion of I/O quantity for multiple modules

Industrial grade stability, suitable for long-term automation control

The HP 44723A is designed specifically for high-speed measurement and control scenarios, with high speed, high stability, and strong scalability. It is the core component of automated testing and digital control systems.

HP 44723A 控制器模块   产品展示
