1.产 品 资 料 介 绍：
HP 44727A 模拟输出模块
- 4 通道独立 DAC 模拟输出，支持电压、电流双模式。
- 单通道可通过跳线配置为单极性 / 双极性电压或单极性电流。
- 电压范围：0 至 + 10.235 V、-10.235 至 + 10.235 V。
- 支持最大 ±20 mA 电流输出，适配工业控制信号。
- 每通道具备远程传感功能，确保测试点输出精度。
- 通道对地可浮至 170 V 峰值，抗共模干扰能力强。
- 通道间或通道至机壳防护电压达 120 V 直流 / 170 V 峰值。
- 负载调整率小于 0.6 mV，输出稳定性出色。
- 输出纹波与噪声小于 2.5 mVrms，信号纯净。
- 源引线允许最大 IR 压降小于 1.5 V，适配长距离连接。
- 内置误差放大、传感放大与输出缓冲，校准便捷。
- 采用组件与端子模块分离设计，维护与校准灵活。
- 端子模块配备跳线与校准电阻，现场配置方便。
- 支持最大 16 AWG 线缆连接，满足工业布线需求。
- 与 HP 3852A/3853A 主机插槽兼容，即插即用。
HP 44727A模拟输出模块 产品英文
HP 44727A Analog Output Module
HP 44727A is a 4-channel DAC analog output module compatible with HP 3852A/3853A data acquisition systems, supporting flexible voltage/current configuration and remote sensing, with excellent accuracy and stability.
4-channel independent DAC analog output, supporting voltage and current dual-mode.
Single channel can be configured as unipolar/bipolar voltage or unipolar current through jumper wires.
Voltage range: 0 to+10.235 V, -10.235 to+10.235 V.
Supports maximum ± 20 mA current output and is compatible with industrial control signals.
Each channel has remote sensing function to ensure the accuracy of the test point output.
The channel can float to a peak voltage of 170 V and has strong resistance to common mode interference.
The protection voltage between channels or channels to the casing reaches a peak of 120 V DC/170 V.
The load adjustment rate is less than 0.6 mV, and the output stability is excellent.
The output ripple and noise are less than 2.5 mVrms, and the signal is pure.
The maximum allowable IR voltage ｄｒｏｐ for the source lead is less than 1.5 V, suitable for long-distance connections.
Built in error amplification, sensor amplification, and output buffering for easy calibration.
Adopting a design that separates components from terminal modules, maintenance and calibration are flexible.
The terminal module is equipped with jumpers and calibration resistors, making on-site configuration convenient.
Supports up to 16 AWG cable connections to meet industrial cabling requirements.
Compatible with HP 3852A/3853A host slots, plug and play.
HP 44727A is a high-precision and highly reliable 4-channel DAC analog output module, suitable for analog signal generation scenarios in automation testing, industrial control, and data acquisition systems.
HP 44727A模拟输出模块 产品展示
