1.产 品 资 料 介 绍：
一、核心定位与架构
- 属于施耐德电气（原 Invensys Triconex）Tricon/Trident 三重冗余（TMR）安全控制系统。
- 采用 ** 三模冗余（TMR）** 架构，内部三路独立处理器并行执行，硬件 2oo3 表决，单点故障不影响安全输出。
- 负责执行安全逻辑、I/O 管理、系统诊断与 TriBus 同步，满足 SIL3 安全等级。
二、关键技术参数
- 处理器：双 32 位微处理器，内部时钟 25MHz。
- 内存：2MB 受保护 Flash（程序）、带 ECC 纠错的 RAM，电池备份时钟。
- 通信：TriBus（4Mbps，16 位 DMA）、隔离 RS-232（诊断）、RS-485（2Mbps）。
- 扫描时间：典型 10–50ms，依程序规模而定。
- 隔离：端口与机箱间 500VDC 电气隔离。
- 功耗：典型 10W。
- 尺寸：约 114×30×185mm，重量约 0.8kg。
- 工作温度：0–60℃。
- 诊断：内部故障检测覆盖率 > 99.9%，实时自诊断。
- 热插拔：支持在线更换，不中断系统运行。
- 编程：兼容 TriStation 1131 开发环境。
- 认证：TÜV 认证，符合 IEC 61508 SIL3 安全标准。
三、主要功能
- 执行 SIS/ESD/F&G 等安全控制逻辑，实现紧急停车与安全联锁。
- 管理系统 I/O 模块，完成数据采集与输出控制。
- 三路处理器同步表决，确保输出安全可靠。
- 实时诊断模块与系统状态，快速定位故障。
- 支持程序备份、恢复与在线调试。
四、应用场景
- 石油化工、油气、电力、冶金等行业的安全仪表系统（SIS）、紧急停车系统（ESD）、火气检测系统（F&G）。
TRICONEX ENOII 3006 输入输出模块 产品英文
The TriconeX 3006 is not a regular I/O module, but the main processor module of the Tricon/Rident TMR safety system, which is the core control unit of the SIS/ESD system.
1、 Core positioning and architecture
Belongs to Schneider Electric's (formerly Invensys Triconex) Tricon/Rident Triple Redundancy (TMR) safety control system.
The * * the third mock examination Redundancy (TMR) * * architecture is adopted, and the internal three independent processors execute in parallel. Hardware 2oo3 votes, and a single point of failure does not affect the safe output.
Responsible for executing safety logic, I/O management, system diagnostics, and TriBus synchronization to meet SIL3 safety level.
2、 Key technical parameters
Processor: Dual 32-bit microprocessors with an internal clock of 25MHz.
Memory: 2MB protected Flash (program), RAM with ECC error correction, battery backup clock.
Communication: TriBus (4Mbps, 16 bit DMA), isolated RS-232 (diagnostic) RS-485（2Mbps）。
Scanning time: typically 10-50ms, depending on the program size.
Isolation: 500VDC electrical isolation between the port and the chassis.
Power consumption: Typical 10W.
Size: approximately 114 × 30 × 185mm, weight approximately 0.8kg.
Working temperature: 0-60 ℃.
Diagnosis: Internal fault detection coverage>99.9%, real-time self diagnosis.
Hot swappable: supports online replacement without interrupting system operation.
Programming: Compatible with TriStation 1131 development environment.
Certification: T Ü V certification, compliant with IEC 61508 SIL3 safety standards.
3、 Main functions
Implement safety control logic such as SIS/ESD/F&G to achieve emergency shutdown and safety interlocking.
Manage system I/O modules to complete data acquisition and output control.
Three processors synchronously vote to ensure safe and reliable output.
Real time diagnosis module and system status, quickly locate faults.
Support program backup, recovery, and online debugging.
4、 Application scenarios
Safety Instrumented Systems (SIS), Emergency Shutdown Systems (ESD), Fire and Gas Detection Systems (F&G) for industries such as petrochemicals, oil and gas, electricity, and metallurgy.
TRICONEX ENOII 3006 输入输出模块 产品展示
产品视频
3.其他产品
YOKOGAWA NFAI841-S00 输入输出模块
PTM.MTNEx 131299S输入输出模块
HIMA X-COM01010 985260010 工控控制模块
4.其他英文产品
83SR06B-E GJR2395400R1210 Input/Output Module
97590-8 BD-PCI4PORT Data Acquisition Card
DS200PCCAG1ABB DC power connection board
| 269PLUS-DO-211-100N-120VAC | SE06000-000000 | IC3600TDTA1 |
| 269PLUS-DO-120N-125VDC | SR06004-000000 | IC3600TDIA1 |
| 269PLUS-DO-120N-120 | S60300-550 | IC3600TCSA1 |
| 269PLUS-DO-100P-125VDC | SMARTSTEP-240 | 073-805000-00 |
| 269PLUS-DO-100P-120 | SS420-10001 | 073-651089-00 |
| 269PLUS-DO-100N-120 | SS400-10082 | 6ES5470-7LC12 |
