JAMSC-B1063输入输出模块

JAMSC-B1063输入输出模块

1.产 品 资 料 介 绍：

1. 适配安川 MEMOCON-SC 系列 PLC 系统，为单轴伺服定位专用模块。
2. 核心功能：脉冲串输出控制、绝对 / 增量定位、编码器反馈采集、单轴闭环控制。
3. 最大脉冲输出频率：500kHz，满足高速定位需求。
4. 控制轴数：1 轴，专注单轴高精度伺服控制。
5. 供电：DC24V，输入 / 输出电流均为 1.2A。
6. 编码器输入：A/B 相 90° 相移，5VDC，支持增量式编码器反馈。
7. 定位模式：支持绝对定位与增量定位两种模式。
8. 工作环境：温度 0~55℃，湿度 5~95% RH（无结露）；存储 - 20~75℃。
9. 绝缘性能：端子间 / 模块 - 外壳绝缘电阻 > 1000MΩ（50VDC）。
10. 安装：DIN 导轨安装，插拔寿命≥100 次。
11. 抗干扰：符合 IEC 61000-4 工业 EMC 标准，适应车间电磁环境。
12. 尺寸：约 75×125×30mm，重量约 0.3kg。
13. 应用场景：数控加工、精密装配、检测设备、小型机器人关节定位。
14. 接口：脉冲输出（CW/CCW 或 PULSE/DIR）、编码器反馈、使能 / 报警等控制信号端子。
15. 保护：过流、过压、过热防护，保障模块与伺服系统安全。

JAMSC-B1063输入输出模块 产品英文

JAMSC-B1063 is a single axis positioning control module (non universal I/O module) for Yaskawa MEMOCON-SC series PLC, used for high-precision pulse control of servo motors.

Compatible with the Yaskawa MEMOCON-SC series PLC system, it is a dedicated module for single axis servo positioning.

Core functions: Pulse train output control, absolute/incremental positioning, encoder feedback acquisition, single axis closed-loop control.

Maximum pulse output frequency: 500kHz, meeting high-speed positioning requirements.

Control axis number: 1 axis, focusing on single axis high-precision servo control.

Power supply: DC24V, input/output current is 1.2A.

Encoder input: A/B phase 90 ° phase shift, 5VDC, supports incremental encoder feedback.

Positioning mode: Supports both absolute positioning and incremental positioning modes.

Working environment: Temperature range of 0-55 ℃, humidity range of 5-95% RH (no condensation); Storage -20~75 ℃.

Insulation performance: Terminal/module shell insulation resistance>1000M Ω (50VDC).

Installation: DIN rail installation, with a plug-in life of ≥ 100 times.

Anti interference: Complies with the IEC 61000-4 industrial EMC standard and adapts to the electromagnetic environment in the workshop.

Size: approximately 75 × 125 × 30mm, weight approximately 0.3kg.

Application scenarios: CNC machining, precision assembly, testing equipment, small robot joint positioning.

Interface: Pulse output (CW/CCW or PULSE/DIR), encoder feedback, enable/alarm and other control signal terminals.

Protection: overcurrent, overvoltage, and overheating protection to ensure the safety of modules and servo systems.

JAMSC-B1063 is the core module of the Yaskawa MEMOCON-SC system for achieving high-precision single axis servo positioning.
