1.产 品 资 料 介 绍：
- 型号：MECOS MBE3-50，主动磁悬浮轴承驱动控制器，50kW 功率等级。
- 核心原理：电磁力无接触悬浮，闭环实时控制，消除机械摩擦。
- 功率适配：额定 50kW，适配高速电机、涡轮机械、压缩机等。
- 控制精度：微米级位移控制，悬浮间隙稳定 ±5μm 内。
- 高速能力：支持最高 50,000+r/min，适配超高速主轴 / 涡轮。
- 实时控制：DSP+FPGA 架构，控制周期≤100μs，响应快。
- 多重保护：过流、过压、短路、超速、失磁保护，安全可靠。
- 传感器接口：适配电涡流 / 激光位移传感器，高精度位置反馈。
- 功耗特性：无润滑、低损耗，较传统轴承节能 30%–50%。
- 长寿命设计：无磨损部件，MTBF≥250,000h，免维护。
- 运行特性：低振动、低噪声，转速波动≤0.1%。
- 保护轴承：内置后备机械轴承，故障时安全着陆。
- 通讯接口：支持工业以太网 / RS485，远程监控与诊断。
- 环境耐受：工业宽温，适配洁净车间 / 高湿工况。
- 典型应用：高速电机、储能飞轮、涡轮鼓风机、分子泵、高速主轴。
The MECOS MBE3-50 drive control magnetic levitation bearing system is a Swiss MECOS high-performance active magnetic bearing (AMB) dedicated drive control system, focusing on high speed, frictionless, and long life, suitable for 50kW level high-speed rotating machinery.
Model: MECOS MBE3-50, active magnetic levitation bearing drive controller, 50kW power level.
Core principle: Electromagnetic force non-contact suspension, closed-loop real-time control, eliminating mechanical friction.
Power adaptation: rated at 50kW, suitable for high-speed motors, turbomachinery, compressors, etc.
Control accuracy: Micro level displacement control, stable suspension gap within ± 5 μ m.
High speed capability: Supports up to 50000+r/min, compatible with ultra high speed spindles/turbines.
Real time control: DSP+FPGA architecture, control cycle ≤ 100 μ s, fast response.
Multiple protections: overcurrent, overvoltage, short circuit, overspeed, demagnetization protection, safe and reliable.
Sensor interface: Suitable for eddy current/laser displacement sensors, high-precision position feedback.
Power consumption characteristics: No lubrication, low loss, energy-saving by 30% -50% compared to traditional bearings.
Long life design: no wear parts, MTBF≥250,000h， Maintenance free.
Operating characteristics: low vibration, low noise, speed fluctuation ≤ 0.1%.
Protective bearings: Built in backup mechanical bearings for safe landing in case of failure.
Communication interface: Supports industrial Ethernet/RS485, remote monitoring and diagnosis.
Environmental tolerance: Industrial wide temperature range, suitable for clean workshops/high humidity conditions.
Typical applications: high-speed motors, energy storage flywheels, turboblowers, molecular pumps, high-speed spindles.
