1.产 品 资 料 介 绍：

1394‑AM75（Allen‑Bradley）伺服驱动器

1. 型号：1394‑AM75（Bulletin 1394），大功率伺服轴模块。
2. 输入：直流母线 530–680VDC，适配 400/480V 三相整流母线。
3. 功率：额定 17.8–23.8kW，连续电流 35A，峰值电流 70A（1s）。
4. 驱动类型：IGBT PWM，适配 AB 1326/1390 系列交流伺服电机。
5. 控制模式：位置 / 速度 / 扭矩闭环，DSP 全数字，电流环 100μs 级。
6. 反馈接口：标配增量式编码器，可选绝对式编码器。
7. 通讯：支持SERCOS、DeviceNet、模拟量 ±10V、脉冲方向。
8. 保护：过流、过压、欠压、过热、短路、失速、编码器故障保护。
9. 精度：速度波动 **<0.05%，定位精度±1 脉冲 **，适合精密定位。
10. 动态：带宽高、响应快，支持高频启停与快速换向。
11. 散热：内置散热器，宽温 0–50℃，适合机柜安装。
12. 结构：模块式，IP20防护，导轨安装，支持多轴拼接。
13. 效率：≥98%，低损耗，节能运行。
14. 诊断：内置故障代码、实时监控，支持上位机诊断。
15. 应用：数控机床、机器人、包装、纺织、造纸、重型多轴设备。

1394-AM75伺服驱动器 产品英文

1394-AM75 (Allen Bradley) servo drive

1394-AM75 is a Rockwell Allen Bradley 1394 series high-power AC servo shaft module with DC bus input and single axis drive. It features high precision, high torque, and high-speed dynamic response, and is used for mid to high end multi axis motion and heavy equipment.

Model: 1394-AM75 (Bulletin 1394), high-power servo shaft module.

Input: DC bus 530-680V, compatible with 400/480V three-phase rectifier bus.

Power: Rated 17.8-23.8kW, continuous current 35A, peak current 70A (1s).

Drive type: IGBT PWM, compatible with AB 1326/1390 series AC servo motors.

Control mode: Position/speed/torque closed-loop, DSP full digital, current loop at 100 μ s level.

Feedback interface: Standard incremental encoder, optional absolute encoder.

Communication: Supports SERCOS, DeviceNet, analog ± 10V, pulse direction.

Protection: overcurrent, overvoltage, undervoltage, overheating, short circuit, stall, encoder fault protection.

Accuracy: Speed fluctuation * *<0.05%, positioning accuracy ± 1 pulse * *, suitable for precise positioning.

Dynamic: High bandwidth, fast response, supports high-frequency start stop and fast commutation.

Heat dissipation: Built in heat sink, wide temperature range of 0-50 ℃, suitable for cabinet installation.

Structure: Modular, IP20 protection, rail mounted, supports multi axis splicing.

Efficiency: ≥ 98%, low loss, energy-saving operation.

Diagnosis: Built in fault codes, real-time monitoring, and support for upper computer diagnosis.

Applications: CNC machine tools, robots, packaging, textiles, papermaking, heavy-duty multi axis equipment.
