Silicon Graphics 030-8216-001印刷电路板
1.产 品 资 料 介 绍：
- 型号为 030-8216-001，是 SGI Indy 原装 PCB 主板。
- 适配 IP20 架构，支持 R4000/R4400 处理器。
- 采用 6 层工业级 PCB，材质稳定、抗弯折。
- 板载集成显卡接口，适配 Indy 图形系统。
- 内置高速内存插槽，支持 ECC 校验。
- 集成 I/O 控制单元，含串口、并口与音频接口。
- 采用表面贴装工艺，焊点均匀、抗干扰强。
- 支持 IRIX 5.3/6.2 系统，兼容性好。
- 板载电源管理模块，供电稳定、功耗低。
- 集成实时时钟（RTC）与 CMOS 存储单元。
- 具备过流、过压保护，延长硬件寿命。
- 标准尺寸设计，适配 Indy 工作站机箱。
- 线路布局优化，信号传输延迟低。
- 原装 SGI 工业品质，长期运行可靠。
- 适用于 SGI Indy 工作站维修与升级替换。
Silicon Graphics 030-8216-001印刷电路板 产品英文
The Silicon Graphics 030-8216-001 printed circuit board is an original motherboard for SGI Indy workstations, belonging to the IP20 architecture, designed specifically for R4000 series processors, with high integration and strong stability.
The model is 030-8216-001, which is an SGI Indy original PCB motherboard.
Compatible with IP20 architecture and supports R4000/R4400 processors.
Using 6-layer industrial grade PCB, the material is stable and resistant to bending.
Onboard integrated graphics card interface, compatible with Indy graphics system.
Built in high-speed memory slot, supports ECC verification.
Integrated I/O control unit, including serial port, parallel port, and audio interface.
Using surface mount technology, the solder joints are uniform and have strong anti-interference ability.
Supports IRIX 5.3/6.2 system with good compatibility.
Onboard power management module, with stable power supply and low power consumption.
Integrate real-time clock (RTC) and CMOS storage unit.
Equipped with overcurrent and overvoltage protection to extend hardware lifespan.
Standard size design, compatible with Indy workstation chassis.
Optimized circuit layout with low signal transmission delay.
Original SGI industrial quality, reliable long-term operation.
Suitable for SGI Indy workstation maintenance and upgrade replacement.
In summary, the 030-8216-001 printed circuit board, with its original adaptability, stable architecture, and complete interfaces, is the core replacement component of SGI Indy workstations, suitable for professional graphics processing and early UNIX system application scenarios.
Silicon Graphics 030-8216-001印刷电路板 产品展示
