Silicon Graphics A17-0503-096 电源模块
1.产 品 资 料 介 绍：
- 型号为 A17-0503-096，SGI Indy 工作站原装电源模块。
- 输入电压 100–240VAC，兼容 50/60Hz 全球市电。
- 额定输出功率 170W，满足 Indy 整机供电需求。
- 多路稳定输出：+3.3V/7A、+5V/25A、+12V/4.5A、-12V/0.75A。
- 自带 + 5V 待机电源，支持远程开机与低功耗待机。
- 采用标准 NEMA C13 交流输入接口，通用性强。
- 主电源输出为 20 针 Molex Mini‑Fit Jr. 接头，适配主板。
- 辅助信号采用 2×10 针 0.1 英寸间距连接器。
- 内置过压、过流、短路、过温四重保护。
- 工业级 EMI 滤波设计，低纹波、低噪声。
- 集成温控风扇，负载自适应调速，兼顾散热与静音。
- 标准尺寸 34×7.5×10cm，适配 Indy 机箱位。
- 全封闭金属外壳，抗干扰、防粉尘、抗震性好。
- 原装 SGI 品质，长期满载运行稳定可靠。
- 即插即用，适合 SGI Indy 维修替换与升级。
Silicon Graphics A17-0503-096 电源模块 产品英文
The Silicon Graphics A17-0503-096 power module is a dedicated original AC power supply for SGI Indy workstations, with a power of 170W, compatible with IP20 architecture, stable power supply, complete interfaces, and complete protection.
Model A17-0503-096, SGI Indy workstation original power module.
Input voltage 100-240VAC, compatible with 50/60Hz global mains power.
The rated output power is 170W, which meets the power supply requirements of the entire Indy machine.
Multi channel stable output:+3.3V/7A,+5V/25A,+12V/4.5A, -12V/0.75A.
Comes with a built-in+5V standby power supply, supporting remote power on and low-power standby.
Adopting the standard NEMA C13 AC input interface, it has strong versatility.
The main power output is a 20 pin Molex Mini Fit Jr. connector, compatible with the motherboard.
The auxiliary signal adopts a 2 × 10 pin 0.1 inch spacing connector.
Built in four fold protection for overvoltage, overcurrent, short circuit, and over temperature.
Industrial grade EMI filtering design, low ripple, low noise.
Integrated temperature control fan, load adaptive speed regulation, balancing heat dissipation and noise reduction.
Standard size 34 × 7.5 × 10cm, suitable for Indy chassis position.
Fully enclosed metal shell, anti-interference, dust-proof, and earthquake resistant.
Original SGI quality, stable and reliable long-term full load operation.
Plug and play, suitable for SGI Indy maintenance, replacement, and upgrade.
In summary, the A17-0503-096 power module is the core power supply component of SGI Indy workstations, suitable for professional graphics processing and UNIX system environments, thanks to its original adaptation, wide input, multi-channel precise output, and complete protection.
Silicon Graphics A17-0503-096 电源模块 产品展示
