1.产 品 资 料 介 绍：
ADAS STB 532 多路总线汇聚卡
ADAS STB 532 多路总线汇聚卡用于多条现场总线信号汇总收纳，实现多路数据集中转发，简化控制柜内部组网布线。
支持多路总线同时接入，可汇聚多组现场板卡传输数据
内置光电隔离模块，有效隔绝工业现场电磁干扰
搭载过压、过流、反接防护，避免接线失误造成硬件损坏
配置多路状态指示灯，可快速排查各路总线通讯故障
标准插卡式安装结构，机柜拆装、备件更换操作简单
工业宽电压供电，电网电压波动环境下运行稳定
宽温工业设计，高低温、潮湿粉尘工况可长期连续工作
镀金金手指接口耐磨抗氧化，电气连接稳定可靠
上电自动硬件自检，实时监测每一路总线链路状态
阻燃线路基板绝缘性优异，有效降低线路短路隐患
内置信号滤波电路，减少杂波干扰，降低数据传输误码
集中式数据转发设计，减轻主控单元的数据处理压力
支持总线分支拓展，方便现场分区布线施工与维护
原厂精密贴片工艺，抗震抗震动，长期运行故障率低
适配 ADAS 同系列工控系统，参数配置简单，兼容性良好
ADAS STB 532 多路总线汇聚卡集成度高、组网便捷，广泛应用于印刷、冶金、化工自动化生产线，是大型工控系统总线集中组网常用核心备件。
ADAS STB 532 多路总线汇聚卡 产品英文
ADAS STB 532 Multi Channel Bus Aggregation Card
The ADAS STB 532 multi bus aggregation card is used for summarizing and storing multiple fieldbus signals, achieving centralized forwarding of multiple data channels and simplifying the internal networking and wiring of control cabinets.
Support simultaneous access of multiple buses, capable of aggregating multiple sets of field cards for data transmission
Built in photoelectric isolation module effectively isolates electromagnetic interference from industrial sites
Equipped with overvoltage, overcurrent, and reverse connection protection to avoid hardware damage caused by wiring errors
Configure multiple status indicator lights to quickly troubleshoot communication faults on various buses
Standard card insertion installation structure, easy operation for cabinet disassembly and replacement of spare parts
Industrial wide voltage power supply, stable operation under fluctuating grid voltage environment
Wide temperature industrial design, capable of long-term continuous operation under high and low temperature, humid dust conditions
Gold plated finger interface, wear-resistant and anti-oxidation, stable and reliable electrical connection
Power on automatic hardware self-test, real-time monitoring of the status of each bus link
Flame retardant circuit boards have excellent insulation properties, effectively reducing the risk of short circuits in the circuit
Built in signal filtering circuit reduces clutter interference and lowers data transmission errors
Centralized data forwarding design, reducing the data processing pressure on the main control unit
Support bus branch expansion, convenient for on-site partition wiring construction and maintenance
Original precision SMT technology, earthquake and vibration resistance, low long-term operation failure rate
Compatible with ADAS industrial control systems of the same series, with simple parameter configuration and good compatibility
The ADAS STB 532 multi bus aggregation card has high integration and convenient networking, and is widely used in printing, metallurgy, and chemical automation production lines. It is a commonly used core spare part for large-scale industrial control system bus centralized networking.
ADAS STB 532 多路总线汇聚卡 产品展示
