PFEIFFER PMP02990A真空泵

PFEIFFER  PMP02990A真空泵

1.产 品 资 料 介 绍：

PFEIFFER PMP02990A 真空泵产品特点

开头：PFEIFFER PMP02990A 为普发 TMH262 系列涡轮分子泵，适配质谱、半导体真空设备，核心特点如下：

额定转速 60000rpm，氮气抽速可达 210L/s，抽气效率高

氮气压缩比超 10⁹，轻松实现超高洁净真空环境

高真空侧永磁无磨损轴承，前级侧陶瓷滚珠轴承，寿命更长

启动时长仅 3.5 分钟，快速抵达目标真空工况

运行噪音低于 50dB (A)，整机振动幅度小

支持风冷、水冷两种散热方案，适配不同安装环境

标准 DN100 ISO-K 进气法兰，DN25 排气接口，通用性强

内置 G1/8 标准放气口，腔体泄压操作便捷

转子最高耐受 90℃，高温工况运行稳定不易故障

搭配 TC100 控制器，支持转速、温度实时监测

干燥无油抽气，不会污染腔体与精密工件

待机转速 40000rpm，待机模式有效降低能耗

适配气相色谱质谱仪、科研真空镀膜设备

整机工业不锈钢壳体，耐腐蚀、防尘抗油污

支持多气体适配，氢气、氦气抽气表现均衡稳定

结尾：PFEIFFER PMP02990A 真空性能稳定、维护简单，是高端精密真空系统核心抽气设备。

PFEIFFER  PMP02990A真空泵   产品英文

PFEIFFER PMP02990A Vacuum Pump Product Features

Introduction: PFEIFFER PMP02990A is a PuFa TMH262 series turbo molecular pump, suitable for mass spectrometry and semiconductor vacuum equipment. Its core features are as follows:

Rated speed 60000rpm, nitrogen pumping speed can reach 210L/s, high pumping efficiency

Nitrogen compression ratio exceeding 10 ⁹, easily achieving ultra-high cleanliness and vacuum environment

High vacuum side permanent magnet wear-resistant bearing, front stage side ceramic ball bearing, longer service life

The startup time is only 3.5 minutes, quickly reaching the target vacuum condition

The operating noise is below 50dB (A), and the overall vibration amplitude of the machine is small

Supports both air-cooled and water-cooled heat dissipation solutions, suitable for different installation environments

Standard DN100 ISO-K intake flange, DN25 exhaust interface, strong universality

Built in G1/8 standard vent, convenient chamber pressure relief operation

The rotor can withstand up to 90 ℃ and operates stably under high temperature conditions, making it less prone to malfunctions

Paired with TC100 controller, supporting real-time monitoring of speed and temperature

Dry and oil-free air extraction, will not contaminate the cavity and precision workpieces

Standby speed of 40000 rpm, standby mode effectively reduces energy consumption

Suitable for gas chromatography-mass spectrometry and research vacuum coating equipment

The whole machine is made of industrial stainless steel shell, which is corrosion-resistant, dustproof and oil resistant

Support multi gas adaptation, with balanced and stable hydrogen and helium pumping performance

Conclusion: PFEIFFER PMP02990A has stable vacuum performance and simple maintenance, making it the core pumping equipment of high-end precision vacuum systems.
