1.产 品 资 料 介 绍：
Rolls-Royce WRC1021A 印刷电路板产品特点
- 原厂标准多层线路板，阻抗匹配精准，信号传输损耗低
- 军工级基板材质，耐高低温，适配机组机房严苛工况
- 大面积接地铜箔层，有效抑制电磁干扰，运行无信号漂移
- 高密度布线设计，集成多路模拟、数字信号输入输出点位
- 全板加厚铜箔走线，承载稳定大电流，供电回路压降小
- 镀厚金焊盘工艺，抗氧化耐腐蚀，长期插拔接触稳定
- 内置板载过流、过压防护线路，避免元件瞬间击穿损坏
- 防震加固布局，抗机组运行持续震动，焊点不易脱焊
- 集成 CAN、Modbus 工业通讯线路，可对接机组上位监控系统
- 预留标准化插槽点位，直插配套传感器、执行器无需转接
- 优化导热铜区设计，长时间满载运行散热均衡不积热
- 全线路绝缘隔离，杜绝相邻回路短路、漏电安全隐患
- 原厂专用元器件丝印标识，故障点位快速检修定位
- 遵循船舶、发电设备安规标准，防潮防油污侵蚀
- 同系列机组通用版型，替换安装无需修改设备线路结尾：Rolls-Royce WRC1021A 稳定性与抗环境能力突出，是劳斯莱斯动力设备核心控制线路板备件。
Rolls-Royce WRC1021A印刷电路板 产品英文
Features of Rolls Royce WRC121A Printed Circuit Board Product
Introduction: Rolls Royce WRC1011A is a dedicated main control printed circuit board for industrial gas turbines and generator sets, responsible for signal acquisition and logic control of the entire machine.
Original factory standard multi-layer circuit board, precise impedance matching, low signal transmission loss
Military grade substrate material, resistant to high and low temperatures, suitable for harsh working conditions in machine rooms
Large area grounded copper foil layer effectively suppresses electromagnetic interference and operates without signal drift
High density wiring design, integrating multiple analog and digital signal input and output points
Thick copper foil wiring throughout the board, capable of carrying stable high currents and low voltage ｄｒｏｐ in the power supply circuit
Thick gold plating pad process, anti-oxidation and corrosion-resistant, stable long-term insertion and extraction contact
Built in onboard overcurrent and overvoltage protection circuits to prevent instantaneous breakdown and damage of components
Seismic reinforcement layout, resistant to continuous vibration during unit operation, and welding points are not easily detached
Integrated CAN and Modbus industrial communication lines, can be connected to the upper monitoring system of the unit
Reserved standardized slot points, direct insertion of matching sensors and actuators without the need for adapters
Optimize the design of the thermal conductive copper zone to achieve balanced heat dissipation and no heat accumulation during long-term full load operation
Insulation isolation of the entire circuit to eliminate safety hazards such as short circuits and leakage in adjacent circuits
Original factory specific components with silk screen markings, quick maintenance and location of fault points
Follow the safety regulations and standards for ships and power generation equipment, prevent moisture and oil pollution erosion
Universal version of the same series of units, replacement installation does not require modification of equipment wiring
Conclusion: The Rolls Royce WRC121A has outstanding stability and environmental resistance, and is a spare part for the core control circuit board of Rolls Royce power equipment.
