PRODRIVE TECHNOLOGIES 6734-1700-1102以太网端口模块
1.产 品 资 料 介 绍：
PRODRIVE TECHNOLOGIES 6734-1700-1102 以太网端口模块
- 搭载千兆以太网硬件，支持 EtherCAT 实时总线，时钟同步精度达微秒级
- 多端口独立网络隔离，运动控制、设备监控数据互不串扰
- 内置硬件信号滤波，抵御车间射频、真空泵电磁干扰
- 全通道电气隔离结构，防静电击穿，适配半导体无尘车间
- 标准热插拔插槽，机柜不停机即可完成更换维护
- 配备链路、运行、故障三色指示灯，快速排查通讯故障
- 可对接多轴伺服驱动器、预对准器、视觉检测单元组网
- 自带存储芯片，保存网络 IP、通讯协议配置，断电不丢失参数
- 工业宽电压供电，电压波动环境下网络不掉线、传输稳定
- PCB 与焊盘加固工艺，设备长期震动运行不易虚焊脱焊
- 数据收发延迟低，载台定位、视觉触发指令响应迅速
- 支持 PoE 供电，简化设备内部布线，降低集成难度
- 浪涌、短路、超温多重硬件防护，异常时自动切断端口回路
- 小型模块化设计，占用机柜空间少，适配狭小设备仓
- 出厂完成网络参数校准，上机可直接接入整机系统量产PRODRIVE TECHNOLOGIES 6734-1700-1102 以太网端口模块是晶圆传输、精密检测设备核心通讯备件，保证多设备协同控制稳定。
PRODRIVE TECHNOLOGIES 6734-1700-1102以太网端口模块 产品英文
PRODRIVE TECHNOLOGY 6734-1700-1102 Ethernet Port Module
PRODRIVE 6734-1700-1102 is a dedicated gigabit Ethernet communication module for semiconductor precision motion equipment, used for high-speed data exchange between robotic arms, probe stations, and optical stages, ensuring real-time synchronous transmission of multi axis servos.
Equipped with Gigabit Ethernet hardware, supporting EtherCAT real-time bus, clock synchronization accuracy reaches microsecond level
Multi port independent network isolation ensures that motion control and device monitoring data do not interfere with each other
Built in hardware signal filtering to resist workshop RF and vacuum pump electromagnetic interference
Full channel electrical isolation structure, anti-static breakdown, suitable for semiconductor dust-free workshops
Standard hot swappable slots, the cabinet can be replaced and maintained without shutting down
Equipped with link, operation, and fault indicator lights, quickly troubleshoot communication faults
Can be connected to multi axis servo drives, pre aligners, and visual inspection unit networking
Equipped with a built-in storage chip, it can save network IP and communication protocol configurations without losing parameters during power outages
Industrial wide voltage power supply, stable transmission without network disconnection in voltage fluctuation environment
PCB and pad reinforcement process, equipment is less prone to virtual soldering and desoldering during long-term vibration operation
Low data transmission and reception latency, fast response to carrier positioning and visual trigger commands
Supports PoE power supply, simplifies internal wiring of devices, and reduces integration difficulty
Multiple hardware protections against surges, short circuits, and overheating, automatically cutting off port circuits in case of abnormalities
Small modular design, occupying less cabinet space, suitable for small equipment compartments
The network parameter calibration is completed at the factory, and it can be directly connected to the entire system for mass production on the machine
PRODRIVE TECHNOLOGY 6734-1700-1102 Ethernet port module is a core communication spare part for wafer transfer and precision inspection equipment, ensuring stable collaborative control of multiple devices.
PRODRIVE TECHNOLOGIES 6734-1700-1102以太网端口模块 产品展示
