Genmark Logosol LS-421-2183E接口模块
1.产 品 资 料 介 绍：
Genmark Logosol LS-421-2183E 接口模块
- 原厂匹配 Genmark 系列晶圆传输机械手，直插式安装无需改线适配
- 多路差分信号通道，稳定传输伺服位置、真空压力检测信号
- 通道独立光电隔离，隔绝射频腔体电磁干扰，避免信号失真
- 内置硬件滤波电路，过滤电机启停产生的杂波脉冲
- 过流、短路、静电冲击多层电路防护，保护主控板卡
- 分区状态指示灯，通讯失效、传感断线故障一眼识别
- 集成数字输入输出点位，联动真空阀、晶圆有无检测传感器
- 板载存储单元，保存机械手通讯协议配置，断电参数不丢失
- 标准金手指插槽结构，模块化拆装，维护更换省时便捷
- 工业沉金 PCB 线路，抗氧化、信号传输损耗更低
- 加固焊盘走线，机械手往复震动工况不易出现虚焊脱焊
- 低延迟信号交互，机械手取放片、定位指令响应迅速
- 兼容 Logosol 全系预对准设备协同通讯，信号兼容度高
- 洁净级板材材质，适配无尘车间恒温恒湿生产环境
- 出厂完成全通道信号校准，上机可直接接入机械手量产Genmark Logosol LS-421-2183E 接口模块为晶圆搬运系统关键中转备件，保障机械手各子部件联动稳定、定位精准。
Genmark Logosol LS-421-2183E接口模块 产品英文
Genmark Logosol LS-421-2183E Interface Module
Genmark Logosol LS-421-2183E is a dedicated signal transfer interface board for semiconductor wafer robotic arms, which enables data exchange between robot control and pre alignment, vacuum sensing, and stage mechanisms.
Original factory matched Genmark series wafer transfer robotic arm, direct insertion installation does not require wire modification and adaptation
Multi channel differential signal channel, stable transmission of servo position and vacuum pressure detection signals
Channel independent optoelectronic isolation to isolate electromagnetic interference from RF cavities and avoid signal distortion
Built in hardware filtering circuit to filter out noise pulses generated by motor start stop
Multi layer circuit protection against overcurrent, short circuit, and electrostatic impact to protect the main control board
Partition status indicator light, quick identification of communication failure and sensor disconnection faults
Integrated digital input and output points, linked with vacuum valves and wafer detection sensors
Onboard storage unit, storing the communication protocol configuration of the robotic arm without losing power-off parameters
Standard gold finger slot structure, modular disassembly and assembly, time-saving and convenient maintenance and replacement
Industrial gold-plated PCB circuit, with lower oxidation resistance and signal transmission loss
Strengthening the routing of solder pads and reducing the risk of virtual soldering and detachment under reciprocating vibration conditions of the robotic arm
Low latency signal interaction, rapid response of robotic arm for picking up and placing pieces and positioning instructions
Compatible with Logosol's full range of pre aligned devices for collaborative communication, with high signal compatibility
Clean grade board material, suitable for constant temperature and humidity production environment in dust-free workshops
Complete full channel signal calibration at the factory, and can be directly connected to a robotic arm for mass production on the machine
The Genmark Logosol LS-421-2183E interface module is a critical intermediate spare part for wafer handling systems, ensuring stable linkage and precise positioning of various sub components of the robotic arm.
