1.产 品 资 料 介 绍：
TEL CX81-050055-V3 印刷电路板
简介
- 多路模拟、数字 IO 通道，采集压力温度传感信号
- 板载通讯电路，对接整机主控传输工艺数据
- 线路分区隔离，抵御洁净车间电磁干扰
- 内置过流、静电防护，保护板载精密芯片
- LED 状态指示灯，快速定位通道断线故障
- 化学镍金表面工艺，长期插拔接触稳定
- 多层高密度布线，信号传输延迟低
- 三防涂层电路板，耐粉尘与微量工艺气体
- 插卡式机架结构，拆装替换维护便捷
- 存储基础工艺参数，断电无需重新标定
- 自带散热铜箔，24 小时连续运行控温稳定
- 丝印通道标识完整，检修接线分辨清晰
- 适配 TEL 全系刻蚀、CVD/PVD 工艺设备
- 模块化元器件布局，局部故障单独更换
- CX81 同系列板卡尺寸接口通用，备件可互换
结尾
TEL CX81-050055-V3印刷电路板 产品英文
TEL CX81-050055-V3 Printed Circuit Board
Introduction
TEL Tokyo Electronics CX81 series original PCB, compatible with etching and thin film deposition semiconductor machines, responsible for cavity signal acquisition and logic control.
Multiple analog and digital IO channels, collecting pressure and temperature sensing signals
Onboard communication circuit, connected to the main control of the whole machine to transmit process data
Line partition isolation to resist electromagnetic interference in clean workshops
Built in overcurrent and electrostatic protection to protect onboard precision chips
LED status indicator light, quickly locate channel disconnection fault
Chemical nickel gold surface process, stable long-term plug-in contact
Multi layer high-density wiring with low signal transmission delay
Three proof coating circuit board, resistant to dust and trace process gases
Plug in card rack structure, easy to disassemble, ｒｅｐｌａｃｅ and maintain
Store basic process parameters, no need to recalibrate after power failure
Equipped with heat dissipating copper foil, 24-hour continuous operation with stable temperature control
The silk screen channel identification is complete, and the maintenance wiring is clearly distinguished
Compatible with TEL's entire range of etching, CVD/PVD process equipment
Modular component layout, separate replacement for local faults
CX81 boards of the same series have universal size interfaces and interchangeable spare parts
ending
TEL CX81-050055-V3 has stable signal transmission, durability, and corrosion resistance. It is an original control PCB accessory specifically designed for semiconductor vacuum chambers.
