WAVESTREAM MBP-000300-D000处理器模块

WAVESTREAM MBP-000300-D000处理器模块

1.产 品 资 料 介 绍：

WAVESTREAM MBP-000300-D000 处理器模块

开头：这款 WAVESTREAM 模块是 300W BUC 射频上变频器配套主控单元，管控射频功率输出与整机运行状态。

内置专用处理芯片，实时运算射频输出参数

精准调控输出功率，保障卫星通信信号稳定

集成多路监测电路，采集电压、电流、温度数据

自带 RS232/485 通讯，支持上位机远程管控

实时驻波检测，异常驻波自动降功率保护功放

多档功率可调，适配不同距离信号传输需求

内置故障自检，过热、过流故障快速识别

铝合金一体散热壳体，长时间运行控温稳定

多规格工业航插接口，配套原厂线缆直接对接

宽直流电压输入，适配野外机房多种供电环境

数字预失真算法，降低射频信号失真损耗

密封防尘机身，适配户外、车载严苛工况

支持运行参数存储，断电后数据不丢失

标准化安装孔位，设备机柜快速固定装配

适配 Ku/C 波段卫星发射射频整套机组

结尾：WAVESTREAM MBP-000300-D000 运算稳定、防护完善，是大功率卫星射频设备核心控制备件。

WAVESTREAM MBP-000300-D000处理器模块  产品英文

WAVETREAM MBP-000300-D000 processor module

Introduction: This WAVETREAM module is a main control unit equipped with a 300W BUC RF up converter, which controls the RF power output and overall operating status of the machine.

Built in dedicated processing chip, real-time calculation of RF output parameters

Accurately regulate output power to ensure stable satellite communication signals

Integrated multi-channel monitoring circuit, collecting voltage, current, and temperature data

Comes with RS232/485 communication and supports remote control by the upper computer

Real time standing wave detection, abnormal standing wave automatic power reduction protection amplifier

Multi level power adjustable, suitable for signal transmission needs at different distances

Built in fault self check, quick identification of overheating and overcurrent faults

Aluminum alloy integrated heat dissipation shell, stable temperature control during long-term operation

Multi specification industrial aviation plug interface, matched with original factory cables for direct docking

Wide DC voltage input, suitable for various power supply environments in field computer rooms

Digital pre distortion algorithm to reduce RF signal distortion loss

Sealed dust-proof body, suitable for harsh outdoor and in car working conditions

Support parameter storage during operation, data will not be lost after power failure

Standardized installation holes, quick fixing and assembly of equipment cabinets

Suitable for Ku/C band satellite launch RF complete set of units

Conclusion: WAVETREAM MBP-000300-D000 has stable operation and complete protection, and is a core control spare part for high-power satellite RF equipment.

WAVESTREAM MBP-000300-D000处理器模块  产品展示

视频展示
