1.产 品 资 料 介 绍：
TEL 2180-021229-V1 PCB 板产品特点
开头
- 基材选用高 TG 板材，耐高温，回流焊无分层起泡
- 线路蚀刻精度高，细线宽线距，适配精密元器件贴片
- 铜箔附着力强，高低温环境不易出现铜皮脱落
- 孔壁均匀厚镀铜，杜绝长期使用孔内氧化断路
- 精准阻抗管控，降低高频信号损耗与串扰干扰
- 完善接地铺铜设计，有效抑制电磁噪声干扰
- 导热过孔密集排布，快速导出元件工作热量
- 绝缘性能优异，高低压线路满足安规隔离标准
- 表面沉金工艺，抗氧化、焊接良率稳定无虚焊
- 尺寸热膨胀系数低，温变环境不易变形偏移
- 通过湿热、盐雾测试，防潮防腐蚀耐用性强
- 机械强度充足，抗震动冲击，设备运行不易损坏
- 阻焊涂层均匀完整，防止线路短路与划伤
- 丝印标识清晰规范，方便检修与元器件装配
- 符合无铅 RoHS 标准，环保适配整机出厂要求
结尾
TEL 2180-021229-V1 PCB板 产品英文
TEL 2180-02129-V1 PCB board product features
beginning
TEL 2180-021229-V1 PCB board is suitable for semiconductor equipment dedicated circuits, with precise process and stable performance, and can adapt to long-term continuous operation conditions of the equipment.
The substrate is made of high TG board, which is resistant to high temperatures and has no delamination or bubbling during reflow soldering
High precision etching of the circuit, wide line spacing for fine lines, suitable for precision component mounting
Copper foil has strong adhesion and is not easily peeled off in high and low temperature environments
Uniform and thick copper plating on the hole wall to prevent oxidation and circuit breaking inside the hole during long-term use
Precise impedance control to reduce high-frequency signal loss and crosstalk interference
Improve the grounding copper laying design to effectively suppress electromagnetic noise interference
Dense arrangement of thermal conductive vias, quickly exporting the working heat of components
Excellent insulation performance, high and low voltage lines meet safety isolation standards
Surface immersion gold process, anti-oxidation, stable welding yield without virtual welding
Low coefficient of thermal expansion in size, not easily deformed or displaced in temperature changing environments
Through wet heat and salt spray testing, it has strong durability against moisture and corrosion
Adequate mechanical strength, resistance to vibration and impact, and less likely to be damaged during equipment operation
The solder mask coating is uniform and complete, preventing short circuits and scratches on the circuit
Clear and standardized silk screen markings facilitate maintenance and component assembly
Compliant with lead-free RoHS standards, environmentally friendly and compatible with the factory requirements of the entire machine
ending
TEL 2180-02129-V1 PCB board combines electrical, heat resistance, and mechanical properties, making it a reliable supporting circuit board for semiconductor equipment.
TEL 2180-021229-V1 PCB板 产品展示
