1.产 品 资 料 介 绍：
NIDEC 142UDC100RBFCA 伺服电机产品特点
开头
- 高扭矩密度永磁绕组，同等机身输出扭矩大，短时过载承载能力强
- 内置高精度编码器闭环反馈，位置采集分辨率高，重复定位误差极小
- 低齿槽转矩转子设计，高低速运行无抖动，低速运转顺滑无爬行
- 原厂精密长效滚珠轴承，密封防尘耐磨，大幅延长整机使用寿命
- 一体化金属壳体散热结构，满载运行温升低，不易触发过热保护
- 分体旋转航空插头，动力线与编码线分离，布线整洁检修便捷
- 适配尼得科全系配套驱动器，参数匹配度高，无需复杂调试适配
- 标准 142 方形法兰安装规格，可直接替换同型号电机，拆装省时
- 机身内置 KTY 温度传感，实时监测绕组温度，提前预警高温故障
- IP65 密封防护等级，防尘防喷淋，洁净车间与轻度潮湿环境均可使用
- 加减速动态平衡控制，启停冲击小，避免晶圆、精密工件磕碰损伤
- 高刚性转子结构，负载扰动下位置稳定，不会出现走位偏移
- 低电感绕组设计，高速换向响应迅速，多轴同步运动同步性优异
- 内置断电保持电磁刹车，停机锁轴牢固，杜绝负载滑落移位
- 无铅绝缘工艺，符合 RoHS 环保标准，适配高端产线整机合规出厂
结尾
NIDEC 142UDC100RBFCA伺服电机 产品英文
NIDEC 142UDC100RBFCA servo motor product features
beginning
NIDEC 142UDC100RBFCA belongs to Unimotor HD DC brushless servo motor. The 142 base is compatible with semiconductor and precision automation equipment transmission shafts, with fast dynamic response and sufficient torque, and can operate continuously with high precision for a long time.
High torque density permanent magnet winding, with high output torque of the same body and strong short-term overload carrying capacity
Built in high-precision encoder closed-loop feedback, high position acquisition resolution, and minimal repeat positioning error
Low cogging torque rotor design, no vibration during high and low speed operation, smooth and crawling during low speed operation
Original precision long-lasting ball bearings, sealed, dustproof and wear-resistant, greatly extending the service life of the whole machine
Integrated metal shell heat dissipation structure, low temperature rise during full load operation, less likely to trigger overheating protection
Split rotating aviation plug, power line and coding line separated, neat wiring and convenient maintenance
Compatible with the entire range of Nidec drivers, with high parameter matching and no need for complex debugging and adaptation
Standard 142 square flange installation specification, can directly ｒｅｐｌａｃｅ motors of the same model, saving time in disassembly and assembly
Built in KTY temperature sensor on the body, real-time monitoring of winding temperature, early warning of high temperature faults
IP65 sealing protection level, dust-proof and spray proof, suitable for use in clean workshops and mildly humid environments
Dynamic balance control for acceleration and deceleration, with minimal start stop impact, to avoid damage from collisions with wafers and precision workpieces
High rigidity rotor structure, stable position under load disturbance, without displacement
Low inductance winding design, fast high-speed commutation response, excellent multi axis synchronous motion synchronization
Built in power-off to maintain electromagnetic brakes, the parking lock shaft is secure, preventing the load from slipping and shifting
Lead free insulation process, compliant with RoHS environmental standards, suitable for high-end production lines and compliant factory delivery of complete machines
ending
The NIDEC 142UDC100RBFCA servo motor combines high dynamics, high precision, and industrial durability, and is a core driving component for precision automation and semiconductor equipment rotary transmission.
NIDEC 142UDC100RBFCA伺服电机 产品展示
视频展示
