1.产 品 资 料 介 绍：
TEL 3D80-001488-V2 电源模块
开头
- 原厂适配 TEL 300mm 干法刻蚀整机，接口、供电参数完全匹配无需改造
- 集成多路独立直流输出，5V/12V/24V 多档位电压，同步供给主控、传感、驱动板卡
- 内置多级 EMI 滤波回路，滤除电网杂波，避免干扰精密信号采集
- 宽交流输入适配，电网电压波动工况下输出电压稳定无漂移
- 每通道独立稳压限流，单路故障不影响其余回路正常供电
- 集成浪涌抑制电路，开机、断电瞬间无电压冲击损坏板卡元件
- 全通道多重硬件防护，过流、过压、欠压、超温即时切断并反馈告警
- 分体式航空插头输出接口，区分腔体、传输、检测支路，布线清晰易检修
- 一体式金属密封散热腔体，满载运行散热均衡，长期工作不易高温宕机
- 实时供电状态监测芯片，可向主控上传各通道电压电流运行数据
- 加厚工业 PCB 搭配三防涂层，防潮防尘，适配半导体洁净车间环境
- 加固元器件焊接工艺，抗设备腔体震动，焊点不易脱焊失效
- 模块化整机结构，机架标准卡位插拔更换，大幅缩短设备停机维修时长
- 低损耗转换电路，整机供电转换效率高，长时间运行发热量低
- 无铅原厂制造工艺，符合 RoHS 标准，满足晶圆产线整机合规要求
结尾
TEL 3D80-001488-V2电源模块 产品英文
TEL 3D80-001488-V2 power module
beginning
TEL 3D80-001488-V2 is an original multi-channel power supply module for Telius T-3044SS etching machine, specially designed for 300mm wafer dry etching equipment. It has multi-channel stable output and complete protection, ensuring uninterrupted process power supply for the machine 24/7.
Original factory compatible TEL 300mm dry etching machine, interface and power supply parameters fully match without the need for modification
Integrated multiple independent DC outputs, 5V/12V/24V multi level voltage, synchronously supplied to the main control, sensing, and driving boards
Built in multi-stage EMI filtering circuit, filtering out power grid clutter and avoiding interference with precision signal acquisition
Wide AC input adaptation, stable output voltage without drift under grid voltage fluctuation conditions
Each channel has independent voltage and current regulation, and a single fault does not affect the normal power supply of other circuits
Integrated surge suppression circuit, no voltage surge damage to board components during power on and off moments
Multiple hardware protections for all channels, instant cut-off and feedback of alarms for overcurrent, overvoltage, undervoltage, and overtemperature
Split type aviation plug output interface, distinguishing between cavity, transmission, and detection branches, with clear wiring and easy maintenance
Integrated metal sealed heat dissipation chamber, balanced heat dissipation during full load operation, and less prone to high temperature shutdown during long-term operation
Real time power supply status monitoring chip, capable of uploading voltage and current operation data of each channel to the main control
Thickened industrial PCB with three anti coating, moisture-proof and dustproof, suitable for semiconductor clean workshop environment
Reinforce the welding process of electronic components, resist equipment cavity vibration, and prevent solder joints from detachment and failure
Modular overall structure, standard card slot insertion and replacement in the rack, significantly reducing equipment downtime for maintenance
Low loss conversion circuit, high power conversion efficiency of the whole machine, low heat generation during long-term operation
Lead free original manufacturing process, compliant with RoHS standards, meets the overall compliance requirements of wafer production lines
ending
The TEL 3D80-001488-V2 power module has stable multi-channel power supply and reliable channel isolation protection, and is the core power supply unit of the complete control system for TEL 300mm dry etching equipment.
