ACS UDMpm2-320A007-QTM3 运动控制控制器
1.产 品 资 料 介 绍：
ACS UDMpm2-320A007-QTM3 运动控制控制器产品特点
- 双轴一体驱动架构，单机可同步管控两路伺服电机
- 宽压 85-265V 交流输入，适配工业通用供电工况
- 单轴持续 7.5A、峰值 15A 输出，单轴功率最高 1.6kW
- 20kHz 环路高速采样，定位响应快、低速抖动极小
- 双回路双反馈控制，微米级精密定位稳定可靠
- 兼容增量、正余弦、绝对值编码器、旋转变压器
- 搭载 EtherCAT 工业总线，多轴组网同步性强
- 自带 8 路数字输入、8 路数字输出，设备信号交互便捷
- 配备 4 路 12 位模拟量输入、2 路模拟量输出
- 内置 STO 安全转矩关断，停机防护保障设备安全
- 支持伺服、无刷、有刷、感应多种电机类型
- 搭载 NanoPWM 伺服算法，静止定位误差达纳米级别
- 金属封闭式机身，抗电磁干扰、防尘抗震耐用
- 配套 ACSPL + 编程，支持轨迹规划与 PLC 逻辑运算
- 标准化机柜安装结构，接线简洁便于整机集成ACS UDMpm2-320A007-QTM3 运动控制控制器是精密设备专用双轴伺服驱动控制器，多轴同步稳定、调试维护简单。
ACS UDMpm2-320A007-QTM3 运动控制控制器 产品英文
ACS UDMpm2-320A007-QTM3 Motion Control Controller Product Features
Dual axis integrated drive architecture, single machine can synchronously control two servo motors
Wide voltage 85-265V AC input, suitable for industrial general power supply conditions
Single axis continuous 7.5A, peak 15A output, maximum single axis power of 1.6kW
20kHz loop high-speed sampling, fast positioning response, minimal low-speed jitter
Dual loop dual feedback control, micrometer level precision positioning, stable and reliable
Compatible with incremental, sine cosine, absolute value encoders, and rotary transformers
Equipped with EtherCAT industrial bus, multi axis networking has strong synchronization
Comes with 8 digital inputs and 8 digital outputs, making device signal interaction convenient
Equipped with 4 channels of 12 bit analog input and 2 channels of analog output
Built in STO safety torque shutdown, shutdown protection ensures equipment safety
Supports multiple types of motors including servo, brushless, brushed, and induction motors
Equipped with NanoPWM servo algorithm, the static positioning error reaches nanometer level
Metal enclosed body, resistant to electromagnetic interference, dustproof, shock resistant and durable
Supporting ACSPL+programming, supporting trajectory planning and PLC logic operations
Standardized cabinet installation structure, simple wiring for easy integration of the entire machine
The ACS UDMpm2-320A007-QTM3 motion control controller is a precision equipment dedicated dual axis servo drive controller, with multi axis synchronization stability and simple debugging and maintenance.
ACS UDMpm2-320A007-QTM3 运动控制控制器 产品展示
