1.产 品 资 料 介 绍：
TEL 5011-000188-11控制器模块 产品英文介绍
TEL 5011-000188-11 is a dedicated controller board for Tokyo Electronic Semiconductor Equipment, mainly used for replacing spare parts of etching equipment and ensuring stable signal processing.
5 product features:
1. Integrated board design, signal acquisition and logic control integration, easy on-site disassembly and replacement.
2. Resistant to process environment interference, filters RF and electromagnetic interference in the cavity, and is less prone to false alarms during operation.
3. Native adaptation to TEL device bus protocol, directly interfaces with the host without modifying the program.
4. Multi channel status signal feedback, fault codes can be transmitted back to the device for easy and quick problem location.
5. Multiple protections on board, self-locking for overvoltage and overcurrent, reducing the risk of damage to other boards.
5 product parameters:
1. The board is powered by DC24V and is compatible with the internal power supply of the equipment cabinet.
2. Support dedicated bus communication within the device to achieve instruction interaction.
3. Multiple digital inputs and outputs, capable of linking valves and sensor components.
4. ｉｎｓｅｒｔ card type backplane installation, align with standard equipment card slots.
5. The working environment temperature is 10-40 ℃, suitable for semiconductor clean process chambers.
5 application areas:
1. TEL series semiconductor etching machine equipment main control spare parts.
2. Signal logic control unit for wafer processing equipment.
3. Etching chamber matching execution component control board.
4. Repair and replacement of faulty TEL old equipment boards.
5. Control components for process equipment cabinets in semiconductor production lines.
Overall, TEL 5011-000188-11 belongs to the equipment exclusive board, and there are many disassembled spare parts on the market. Before using it, it is necessary to check the part number and version to ensure compatibility with the entire system
