HONEYWELL MC-PDIY22 80363972-150数字输入模块
1.产 品 资 料 介 绍：
中文资料：
一、基本信息
产品型号：MC-PDIY22
部件号：80363972-150
制造商：Honeywell（霍尼韦尔）
模块类型：数字输入模块（Digital Input Module）
系列归属：Experion PKS / C300 控制系统组件之一
安装平台：一般用于 Honeywell 控制柜 I/O 背板系统（例如 Universal I/O 架构）
二、功能特性
通道数量：
共 16 路数字输入通道
每通道均为独立隔离输入，支持状态监测
输入类型：
直流电平输入（DC digital input）
通常支持 24V DC 信号
支持干接点或有源接点输入模式（需配置）
通道隔离：
通道与通道之间，以及通道与系统总线之间具有电气隔离
增强抗干扰能力，适用于工业复杂现场环境
状态指示：
前面板具备 LED 指示灯，可实时显示每通道的 ON/OFF 状态
便于调试与故障排查
三、电气性能
工作电压范围：通常为 18–30V DC（标称 24V DC）
输入阻抗：高输入阻抗设计，适配广泛类型的输入设备
通道扫描时间：高速采样，满足实时控制系统需求
功耗：低功耗设计，适合大规模 I/O 模块并行部署
四、系统兼容性
适配控制器：适用于 Honeywell C300、HC900、Experion LX 等控制平台
系统通讯：通过 Honeywell I/O 背板总线连接控制器，非直接以太网或现场总线通信
兼容结构：
支持热插拔（Hot Swap）
模块更换无需系统断电，可提升系统可用性
英文资料：
1、 Basic Information
Product model: MC-PDIY22
Part number: 80363972-150
Manufacturer: Honeywell
Module type: Digital Input Module
Series affiliation: One of the components of the control system for Expert PKS/C300
Installation Platform: Generally used for Honeywell control cabinet I/O backplane systems (such as Universal I/O architecture)
2、 Functional characteristics
Number of channels:
There are a total of 16 digital input channels
Each channel is an independent isolated input, supporting status monitoring
Input type:
DC digital input
Usually supports 24V DC signal
Support dry contact or active contact input mode (configuration required)
Channel isolation:
There is electrical isolation between channels, as well as between channels and the system bus
Enhance anti-interference capability, suitable for complex industrial site environments
Status indication:
The front panel is equipped with LED indicator lights, which can display the ON/OFF status of each channel in real time
Easy to debug and troubleshoot
3、 Electrical performance
Working voltage range: typically 18-30V DC (nominal 24V DC)
Input impedance: High input impedance design, suitable for a wide range of input devices
Channel scanning time: high-speed sampling to meet the requirements of real-time control systems
Power consumption: Low power design, suitable for parallel deployment of large-scale I/O modules
4、 System compatibility
Adaptive controller: suitable for control platforms such as Honeywell C300, HC900, and Expert LX
System communication: Connect the controller through Honeywell I/O backplane bus, without direct Ethernet or fieldbus communication
Compatible structure:
Support Hot Swap
Module replacement does not require system power outage, which can improve system availability
