KEBA E-8-ANALOG/C控制板
1.产 品 资 料 介 绍：
KEBA E-8-ANALOG/C 是 KEBA 自动化系统中的一款模拟量输入/输出控制板，通常用于采集外部模拟信号（如电压、电流、温度）并将其传输给主控制系统进行处理，也可作为模拟信号的输出接口控制外部设备。此类模块常用于注塑、包装、机器人系统中的过程控制环节。
技术参数：
模块类型：模拟量输入/输出控制板
通道数量：8 路通道（可配置为输入或输出，具体版本可能略有不同）
输入信号类型：
电压输入：0～10V，±10V
电流输入：0～20 mA，4～20 mA（可选）
输出信号类型：
电压输出：0～10V
电流输出：4～20 mA（仅限支持版本）
A/D 转换精度：12～16 位（视型号而定）
响应时间：典型小于 10 ms
绝缘方式：通道对系统隔离，抗干扰能力强
供电电压：24V DC（±10%）
状态显示：板载 LED 状态指示灯
安装方式：插板式或背板连接
工作环境：温度 0～50°C，湿度 < 85%（无凝露）
应用领域：
1. 注塑/橡胶机械温度与压力控制
采集热电偶放大器输出、电压型压力传感器信号
控制比例阀、加热器等设备的模拟驱动信号输出
2. 过程控制系统
用于采集流量、液位、速度、张力等连续变量
精确输出控制信号用于调节阀、变频器、比例执行器等
3. 包装与印刷设备
控制热封温度、张力反馈、伺服电压调节等
实现同步控制与模拟反馈回路闭环控制
4. 工业机器人平台
接收外部传感器或力控装置的模拟输入信号
输出模拟控制信号至末端执行器、电动夹爪等
5. 设备状态采集与控制系统集成
采集设备状态或环境变量（温度、电流、电压）用于系统预警或分析
输出信号用于外部设备驱动或联动逻辑控制
英文资料：
KEBA E-8-ANALOG/C is an analog input/output control board in KEBA automation systems, typically used to collect external analog signals (such as voltage, current, temperature) and transmit them to the main control system for processing. It can also serve as an output interface for analog signals to control external devices. This type of module is commonly used in the process control links of injection molding, packaging, and robot systems.
Technical parameters:
Module type: Analog input/output control board
Number of channels: 8 channels (configurable as input or output, specific versions may vary slightly)
Input signal type:
Voltage input: 0-10V, ± 10V
Current input: 0-20 mA, 4-20 mA (optional)
Output signal type:
Voltage output: 0-10V
Current output: 4-20 mA (only for supported versions)
A/D conversion accuracy: 12-16 bits (depending on the model)
Response time: typically less than 10 ms
Insulation method: The channel isolates the system and has strong anti-interference ability
Power supply voltage: 24V DC (± 10%)
Status display: onboard LED status indicator light
Installation method: plug-in or backplane connection
Working environment: temperature 0-50 ° C, humidity<85% (no condensation)
Application areas:
1. Temperature and pressure control of injection molding/rubber machinery
Collect thermocouple amplifier output and voltage type pressure sensor signal
Analog drive signal output for controlling proportional valves, heaters, and other equipment
2. Process control system
Used for collecting continuous variables such as flow rate, liquid level, speed, tension, etc
Accurate output control signals are used to regulate valves, frequency converters, proportional actuators, etc
3. Packaging and printing equipment
Control heat sealing temperature, tension feedback, servo voltage regulation, etc
Implement synchronous control and analog feedback loop closed-loop control
4. Industrial Robot Platform
Receive analog input signals from external sensors or force control devices
Output analog control signals to end effectors, electric grippers, etc
5. Integration of equipment status acquisition and control system
Collect device status or environmental variables (temperature, current, voltage) for system warning or analysis
Output signals are used for external device driving or linkage logic control
2.产 品 展 示
