Atlas Copco PF4000-C-PN-HW驱动器

Atlas Copco  PF4000-C-PN-HW驱动器

1.产 品 资 料 介 绍：

Atlas Copco PF4000-C-PN-HW 驱动器

产品概述：
PF4000-C-PN-HW 是 Atlas Copco Power Focus 4000 系列中的一款驱动器型号，用于控制和驱动特定型号的电动拧紧工具。该驱动器集成了扭矩控制、电机管理和通信接口功能，是工业装配过程中关键的控制单元。

命名解析：

• PF4000：代表 Power Focus 4000 系列

• C：表明是单通道控制单元

• PN：支持 PROFINET 通信协议

• HW：表示为硬件版本控制器（通常区别于软件激活版本）

主要功能：

• 精确控制拧紧扭矩与角度

• 与 Tensor ST/STB/SRT 系列工具兼容

• 支持多种拧紧策略（扭矩、角度、时间、组合等）

• 提供故障检测与数据记录功能

• 可集成进自动化系统，连接 MES 或 PLC

• 实时过程监控与数据追溯

• 支持工位互锁和 I/O 控制

通信接口：

• PROFINET（工业以太网）

• USB、RS232

• 可选支持 Open Protocol、以太网/IP、DeviceNet 等（取决于配置）

应用领域：

• 汽车制造及底盘总成

• 电子产品装配

• 电气设备生产

• 高可靠性工业连接场景

• 需要多工位过程控制与追溯的装配产线

英文资料：

Atlas Copco PF4000-C-PN-HW Driver

Product Overview:

PF4000-C-PN-HW is a driver model in the Atlas Copco Power Focus 4000 series, used to control and drive specific models of electric tightening tools. This driver integrates torque control, motor management, and communication interface functions, and is a key control unit in industrial assembly processes.

Naming resolution:

PF4000: represents the Power Focus 4000 series

C: Indicating that it is a single channel control unit

PN: Supports PROFINET communication protocol

HW: stands for Hardware Version Controller (usually distinguished from Software Activation Version)

Main functions:

Precise control of tightening torque and angle

Compatible with Tensor ST/STB/SRT series tools

Support multiple tightening strategies (torque, angle, time, combination, etc.)

Provide fault detection and data recording functions

Can be integrated into automation systems and connected to MES or PLC

Real time process monitoring and data tracing

Support workstation interlocking and I/O control

Communication interface:

PROFINET (Industrial Ethernet)

USB、RS232

Optional support for Open Protocol, Ethernet/IP, DeviceNet, etc. (depending on configuration)

Application areas:

Automobile manufacturing and chassis assembly

Electronic product assembly

Electrical equipment production

High reliability industrial connectivity scenarios

Assembly production lines that require multi station process control and traceability

2.产      品      展      示
