Atlas Copco PF4000-C-HW对焦工具控制器
1.产 品 资 料 介 绍：
一、产品概述
ATLAS COPCO PF4000-C-HW 是 Atlas Copco PF4000 系列中的一款高性能电动工具控制器，主要用于工业装配过程中的对焦/拧紧工具控制。该控制器配合电动拧紧工具（如 Tensor ST 系列）使用，通过高度可编程的扭矩控制、角度控制和过程监控功能，实现高精度、高可靠性的螺栓连接任务。
二、技术参数（简要）
支持工具类型：Tensor ST、SR、ES、ETX 等电动工具
控制方式：扭矩控制 / 角度控制 / 时间控制 / 阶段控制等
通信接口：以太网、RS232、I/O、ProfiBus、DeviceNet、EtherCAT（根据配置）
数据管理功能：支持数据存储、追溯、参数设置下载
人机界面支持：可配触摸面板或连接到工厂MES系统
安装形式：控制柜安装或产线嵌入式安装
三、应用领域
ATLAS COPCO PF4000-C-HW 主要用于以下工业自动化和高端制造场景：
1. 汽车制造
发动机、变速箱装配的关键螺栓拧紧
底盘系统螺栓连接（如悬挂、转向系统）
车身结构部件的高精度拧紧作业
2. 轨道交通
列车车体组装中的关键连接件拧紧控制
制动系统、悬挂结构等高强度螺栓应用
3. 航空航天
航空器结构件的精密组装
对连接扭矩和角度要求极高的部件装配
4. 新能源与电池
动力电池模组组装的螺栓拧紧控制
电驱动系统的结构组装精密控制
5. 家电与电子制造
对高重复精度、低扭矩需求的装配作业
适用于控制小螺丝、高速批量组装生产线
6. 工业机械制造
精密设备结构件连接
工业机器人、机床等整机装配过程
英文资料：
1、 Product Overview
ATLAS COPCO PF4000-C-HW is a high-performance power tool controller in the Atlas Copco PF4000 series, mainly used for focusing/tightening tool control in industrial assembly processes. This controller is used in conjunction with electric tightening tools (such as Tensor ST series) to achieve high-precision and high reliability bolt connection tasks through highly programmable torque control, angle control, and process monitoring functions.
2、 Technical parameters (brief)
Supported tool types: Tensor ST, SR, ES, ETX and other power tools
Control methods: torque control/angle control/time control/stage control, etc
Communication interfaces: Ethernet, RS232, I/O, ProfiBus, DeviceNet, EtherCAT (depending on configuration)
Data management function: supports data storage, traceability, parameter setting download
Human machine interface support: can be equipped with a touch panel or connected to the factory MES system
Installation form: Control cabinet installation or embedded installation on the production line
3、 Application Fields
ATLAS COPCO PF4000-C-HW is mainly used in the following industrial automation and high-end manufacturing scenarios:
1. Automobile manufacturing
Tightening of key bolts for engine and gearbox assembly
Chassis system bolt connections (such as suspension and steering systems)
High precision tightening operation of vehicle structural components
2. Rail Transit
Tightening control of key connecting components in train body assembly
Application of high-strength bolts in braking systems, suspension structures, etc
3. Aerospace
Precision assembly of aircraft structural components
Assembly of components with extremely high requirements for connection torque and angle
4. New energy and batteries
Bolt tightening control for power battery module assembly
Precision control of structural assembly of electric drive system
5. Home appliances and electronic manufacturing
Assembly operations with high repeatability and low torque requirements
Suitable for controlling small screws and high-speed batch assembly production lines
6. Industrial machinery manufacturing
Precision equipment structural component connection
Assembly process of industrial robots, machine tools, and other complete machines
