1.产 品 资 料 介 绍：
XVME-505/2 是 Xycom 推出的 3U 单高单宽 VME 总线 4 通道模拟输出模块，支持电压 / 电流双模式输出，专为工业过程控制、闭环调节与模拟信号驱动场景设计。
- 采用 3U 单高单宽 VME 架构，单插槽占用，兼容标准 VME 背板。
- 提供 4 路独立模拟输出通道，每通道可独立配置为电压或电流模式。
- 电压输出范围：0–5V、0–10V、±5V、±10V（单 / 双极性可选）。
- 电流输出范围：4–20mA 标准电流环，适配工业变送器与执行器。
- 输出分辨率：12 位 D/A 转换，精度 ±0.5 LSB，线性度优异。
- 电压输出驱动能力：±10mA（满量程），电流环驱动能力：24V 回路兼容。
- 输出更新速率：最高 10 kHz，满足快速闭环控制需求。
- 通道间隔离：无通道隔离，共地设计，简化系统布线。
- 占用 1KB VME 短 I/O 地址空间，基址通过板载跳线配置。
- 支持 VME 中断，可配置输出完成 / 错误中断，提升系统响应。
- 电源需求：+5V@0.8A（典型）/1.0A（最大），无额外辅助电源。
- 工作温度：0–65℃，存储温度：-40–85℃，适应工业环境。
- 尺寸：3U VME 标准（160mm × 100mm），适配紧凑型 VME 机箱。
- 兼容 VMEbus A16:D08 (O) 从设备规范，适配主流 VME 控制系统。
- 典型应用：工业过程控制、阀门驱动、仪表校准、闭环调节、模拟信号仿真。
XYCOM XVME-505/2分析 I/O 模块 英文资料：
Xycom XVME-505/2 Analog Output Module (Analyzing I/O)
XVME-505/2 is a 3U single height single width VME bus 4-channel analog output module launched by Xycom, which supports voltage/current dual-mode output and is designed for industrial process control, closed-loop regulation, and analog signal drive scenarios.
Adopting a 3U single height single width VME architecture, occupying a single slot and compatible with standard VME backboards.
Provide 4 independent analog output channels, each channel can be independently configured as voltage or current mode.
Voltage output range: 0-5V, 0-10V, ± 5V, ± 10V (single/bipolar optional).
Current output range: 4-20mA standard current loop, suitable for industrial transmitters and actuators.
Output resolution: 12 bit D/A conversion, accuracy ± 0.5 LSB, excellent linearity.
Voltage output driving capability: ± 10mA (full range), current loop driving capability: 24V circuit compatible.
Output ｕｐｄａｔｅ rate: up to 10 kHz, meeting the requirements of fast closed-loop control.
Channel isolation: No channel isolation, common ground design, simplified system wiring.
Occupying 1KB of VME short I/O address space, the base address is configured through onboard jumpers.
Support VME interrupts, configurable output completion/error interrupts to enhance system response.
Power requirements:+ 5V@0.8A (Typical)/1.0A (maximum), no additional auxiliary power supply.
Working temperature: 0-65 ℃, storage temperature: -40-85 ℃, suitable for industrial environments.
Size: 3U VME standard (160mm × 100mm), suitable for compact VME chassis.
Compatible with VMEbus A16: D08 (O) device specifications and compatible with mainstream VME control systems.
Typical applications: industrial process control, valve drive, instrument calibration, closed-loop regulation, analog signal simulation.
XVME-505/2 has the core advantages of voltage/current dual-mode, 4-channel independent configuration, and high-speed updates. It is a classic module for analog output and process control in VME systems, compatible with pins of the same series XVME-595/2 (6U version), and can flexibly adapt to different chassis sizes.
XYCOM XVME-505/2分析 I/O 模块 产品展示
