XYCOM XVME-956扩展托架模块

1.产 品 资 料 介 绍：

XYCOM XVME-956 扩展托架模块（PC/AT I/O Expansion Carrier）

1. 采用单槽 6U VME 总线结构，仅占用 1 个 VME 插槽，节省机架空间。
2. 内置2 个 PC/104 开放架构扩展位，支持 PC/AT/XT 接口子模块，兼容第三方 PC/104 模块。
3. 提供针座式连接器（无卡边接口），连接可靠、安装便捷。
4. 支持XVME-956/101 内存模块、956/400 串并口模块、956/402 SCSI 适配器、956/411 以太网模块等原厂子模块。
5. 兼容XVME-675、682 等 PC/AT 架构处理器模块，无缝扩展网络、存储、串口等功能。
6. 前面板集成子模块 I/O 接口，便于现场接线与调试。
7. 板载电源稳压电路，为 PC/104 子模块提供稳定供电，保障扩展功能可靠运行。
8. 工业级设计，工作温度 0℃~+55℃，抗电磁干扰，适配工业现场环境。
9. 支持PC/AT 标准总线协议，兼容 DOS、Windows 等操作系统，软件生态成熟。
10. 采用双载板设计（XVME-956/1 与 956/12），适配不同尺寸 PC/104 模块（Type A/B）。
11. 支持无盘启动，搭配固态存储子模块，提升系统可靠性与抗振性。
12. 内置总线缓冲与信号隔离，保护主机与扩展模块，增强系统稳定性。
13. 前面板带状态 LED，实时显示电源、总线与子模块工作状态。
14. 兼容VME64/VMEbus 标准，支持 A32/A24/A16 地址与 D32/D16 数据传输。
15. 适用于工业自动化、DCS 控制、数据采集、测试测量、嵌入式实时系统等场景。

XYCOM XVME-956扩展托架模块  英文资料：

XYCOM XVME-956 Expansion Carrier Module (PC/AT I/O Expansion Carrier)

XVME-956 is a single slot 6U VME bus I/O expansion bracket designed by XYCOM specifically for XVME-67x/68x series VMEbus PC/AT processor modules. It uses PC/104 open architecture to achieve flexible I/O expansion and is suitable for industrial control, data acquisition and other scenarios.

Adopting a single slot 6U VME bus structure, it only occupies one VME slot, saving rack space.

Built in 2 PC/104 open architecture extension bits, supporting PC/AT/XT interface submodules, compatible with third-party PC/104 modules.

Provide needle socket connectors (without card edge interface), with reliable connection and easy installation.

Supports original submodules such as XVME-956/101 memory module, 956/400 serial parallel port module, 956/402 SCSI adapter, 956/411 Ethernet module, etc.

Compatible with PC/AT architecture processor modules such as XVME-675 and 682, seamlessly expanding network, storage, serial port, and other functions.

The front panel integrates submodule I/O interfaces for easy on-site wiring and debugging.

The onboard power supply stabilizing circuit provides stable power supply for the PC/104 submodule, ensuring reliable operation of extended functions.

Industrial grade design, working temperature from 0 ℃ to+55 ℃, anti electromagnetic interference, suitable for industrial site environment.

Supports PC/AT standard bus protocol, compatible with operating systems such as DOS and Windows, and has a mature software ecosystem.

Adopting a dual board design (XVME-956/1 and 956/12), it is compatible with PC/104 modules of different sizes (Type A/B).

Supports diskless boot and is paired with solid-state storage submodules to enhance system reliability and vibration resistance.

Built in bus buffer and signal isolation protect the host and expansion module, enhancing system stability.

The front panel is equipped with a status LED, which displays the real-time working status of the power supply, bus, and submodules.

Compatible with VME64/VMEbus standards, supporting A32/A24/A16 address and D32/D16 data transmission.

Suitable for industrial automation, DCS control, data acquisition, testing and measurement, embedded real-time systems and other scenarios.
