IMDSO02数字输出模块

IMDSO02数字输出模块

1.产 品 资 料 介 绍：

IMDSO02数字输出模块产品特点（15条）

1. 配置8路独立晶体管输出通道，采用PNP源输出模式，专属24VDC负载适配，响应速度优于继电器型模块。

2. 单通道额定输出电流2A，峰值负载电流可达3A，触点耐压30VDC，精准驱动小型电磁阀、指示灯等精密执行元件。

3. 输出响应延迟低至50μs（导通）/100μs（关断），支持100Hz高频开关动作，适配高速循环控制场景。

4. 深度兼容ABB贝利INFI 90 DCS系统，可直接替换老旧模块，无需重构控制程序与硬件架构，升级成本低。

5. 通道与背板总线间采用光电隔离设计，隔离电压达2500VAC，搭配RS485接口600W浪涌保护，抗干扰能力升级。

6. 原生支持Modbus RTU协议，可拓展PROFINET通信模块，实现与西门子、罗克韦尔等异构控制器无缝对接。

7. 宽温工作范围覆盖-30℃至60℃，水平安装时高温工况负载能力自适应调节，适配高海拔、低温工业场景。

8. 内置模块级电源监控与通道级短路保护，故障时自动关断通道并上报告警，避免负载与模块双向损坏。

9. 配备三色LED指示灯组，绿色指示通道输出、红色提示故障、黄色反馈电源状态，运维诊断直观高效。

10. 采用超紧凑型设计，宽度仅15mm，标准化DIN导轨安装，大幅节省控制柜内安装空间，便于密集布局。

11. 支持PWM脉冲宽度调制输出，可通过占空比调节实现执行机构无级调速、调光控制，功能扩展性更强。

12. 具备机械编码键定位功能，防止模块错插误装，搭配自动编码识别，接入系统后无需手动配置地址。

13. 采用9-27VDC宽幅供电设计，具备反接保护功能，避免现场接线失误导致模块烧毁，安全性更优。

14. 支持两通道并联冗余控制，可提升关键负载驱动可靠性，适配对运行连续性要求高的工业场景。

15. 采用贴片式元器件与密封封装工艺，功耗低至1W，无风扇设计，长期运行稳定性优于常规模块。

16. 符合UL、CE及IEC 61131-2标准，通过多维度工业认证，广泛适用于水处理、自动化生产线、物流仓储等场景。

IMDSO02数字输出模块 英文资料：

IMDSO02 Digital Output Module Product Features (15)

1. Configure 8 independent transistor output channels, using PNP source output mode, dedicated 24VDC load adaptation, and response speed better than relay type modules.

2. The rated output current of a single channel is 2A, the peak load current can reach 3A, the contact withstand voltage is 30VDC, and it accurately drives small solenoid valves, indicator lights, and other precision actuators.

3. The output response delay is as low as 50 μ s (on)/100 μ s (off), supporting 100Hz high-frequency switching action, suitable for high-speed cyclic control scenarios.

4. Deeply compatible with ABB Beli INFI 90 DCS system, it can directly ｒｅｐｌａｃｅ old modules without the need to reconstruct control programs and hardware architecture, with low upgrade costs.

5. The channel and backplane bus are designed with optoelectronic isolation, with an isolation voltage of up to 2500VAC, paired with RS485 interface 600W surge protection, and upgraded anti-interference capability.

6. Native support for Modbus RTU protocol, expandable PROFINET communication module, achieving seamless integration with heterogeneous controllers such as Siemens and Rockwell.

7. The wide temperature working range covers -30 ℃ to 60 ℃, and the load capacity of high temperature working conditions is adaptively adjusted when installed horizontally, suitable for high-altitude and low-temperature industrial scenarios.

8. Built in module level power monitoring and channel level short circuit protection, automatically shuts off the channel and reports an alarm when a fault occurs, avoiding bidirectional damage between the load and the module.

9. Equipped with a three color LED indicator light group, green indicator channel output, red fault prompt, and yellow feedback power status, the operation and maintenance diagnosis is intuitive and efficient.

10. Adopting an ultra compact design with a width of only 15mm and standardized DIN rail installation, it greatly saves installation space inside the control cabinet and facilitates dense layout.

11. Supports PWM pulse width modulation output, and can achieve stepless speed regulation and dimming control of the actuator through duty cycle adjustment, with stronger functional scalability.

12. Equipped with mechanical coding key positioning function to prevent module misplacement and installation, coupled with automatic coding recognition, there is no need to manually configure the address after connecting to the system.

13. Adopting a 9-27VDC wide power supply design, it has reverse connection protection function to avoid module burnout caused by on-site wiring errors, and has better safety.

14. Support two channel parallel redundant control, which can improve the reliability of key load driving and adapt to industrial scenarios with high requirements for continuous operation.

15. Adopting surface mounted components and sealed packaging technology, the power consumption is as low as 1W, and the fanless design ensures better long-term stability than conventional modules.

16. Compliant with UL, CE, and IEC 61131-2 standards, with multi-dimensional industrial certification, widely applicable in scenarios such as water treatment, automated production lines, logistics and warehousing.
