IMDSO01数字输出模块

IMDSO01数字输出模块

1.产 品 资 料 介 绍：

IMDSO01数字输出模块产品特点（15条）

1. 配置8路独立数字输出通道，支持继电器干接点输出，兼容24VDC/220VAC负载，适配多类型执行机构。

2. 单通道最大负载电流达5A，触点耐压250VAC，可直接驱动电磁阀、接触器等工业负载，无需中间继电器。

3. 支持RS-485双绞线串行通讯，通讯距离可达1000m，远距离场景可拓展光纤或无线通讯方式。

4. 无缝兼容ABB贝利DCS控制系统，可直接接入原有控制架构，实现与下位机PLC的数据高效交互。

5. 通道间采用电气隔离设计，隔离电压≥1500VAC，有效抵御工业现场电磁干扰，保障信号稳定。

6. 兼容Modbus RTU、Profibus DP主流工业协议，灵活对接各类工控上位机与控制器，通用性强。

7. 工作温度覆盖-20℃至60℃，相对湿度5%-95%（无冷凝），耐受高低温、潮湿等严苛工况。

8. 内置触点状态反馈功能，可实时监测输出回路通断状态，精准定位负载故障，运维更高效。

9. 配备双色LED指示灯，分模块运行状态与通道输出状态，可视化反馈工作情况，故障排查便捷。

10. 采用标准化DIN导轨安装，工业级阻燃外壳防护等级达IP20，防尘防油污，适配控制柜内安装。

11. 支持电平信号与脉冲信号输出模式，可满足连续控制与间歇触发等多样化工业控制需求。

12. 内置过流、短路保护电路，自动切断故障通道，避免模块及前端执行机构损坏，安全性优异。

13. 支持参数远程配置与状态监控，无需现场拆卸模块，降低工业现场维护成本与工作量。

14. 采用可拆卸插拔式终端块，接线牢固抗振动，支持预接线操作，大幅提升现场安装效率。

15. 符合IEC工业安全标准及CE认证，严苛把控产品可靠性，适用于石化、电力、冶金等多行业场景。

IMDSO01数字输出模块 英文资料：

IMDSO01 Digital Output Module Product Features (15)

1. Configure 8 independent digital output channels, support relay dry contact output, compatible with 24VDC/220VAC loads, and adaptable to multiple types of actuators.

2. The maximum load current of a single channel can reach 5A, and the contact withstand voltage is 250VAC. It can directly drive industrial loads such as solenoid valves and contactors without the need for intermediate relays.

3. Supports RS-485 twisted pair serial communication, with a communication distance of up to 1000m, and can be extended to fiber optic or wireless communication methods in long-distance scenarios.

4. Seamless compatibility with ABB Beli DCS control system, can directly connect to the original control architecture, and achieve efficient data exchange with the lower level PLC.

5. Electrical isolation design is adopted between channels, with an isolation voltage of ≥ 1500VAC, effectively resisting electromagnetic interference in industrial sites and ensuring signal stability.

6. Compatible with mainstream industrial protocols such as Modbus RTU and Profibus DP, flexible docking with various industrial control upper computers and controllers, with strong universality.

7. The working temperature ranges from -20 ℃ to 60 ℃, with a relative humidity of 5% -95% (non condensing), and can withstand harsh working conditions such as high and low temperatures, humidity, etc.

8. Built in contact status feedback function, which can monitor the on/off status of the output circuit in real time, accurately locate load faults, and ensure more efficient operation and maintenance.

9. Equipped with dual color LED indicator lights, it divides module operation status and channel output status, visualizes feedback on work status, and facilitates troubleshooting.

10. Adopting standardized DIN rail installation, the industrial grade flame-retardant shell has a protection level of IP20, is dust-proof and oil proof, and is suitable for installation inside control cabinets.

11. Supports level signal and pulse signal output modes, which can meet diverse industrial control needs such as continuous control and intermittent triggering.

12. Built in overcurrent and short-circuit protection circuits, automatically cutting off fault channels to avoid damage to modules and front-end actuators, with excellent safety.

13. Support remote parameter configuration and status monitoring, without the need for on-site module disassembly, reducing maintenance costs and workload in industrial sites.

14. Adopting detachable plug-in terminal blocks, the wiring is firm and vibration resistant, supporting pre wiring operations, greatly improving on-site installation efficiency.

15. Complies with IEC industrial safety standards and CE certification, rigorously controls product reliability, and is suitable for various industry scenarios such as petrochemicals, power, metallurgy, etc.

IMDSO01数字输出模块  产品展示

产品视频
