IMDSM04交响脉冲输入模块

IMDSM04交响脉冲输入模块

1.产 品 资 料 介 绍：

IMDSM04交响脉冲输入模块产品特点（15条）

1. 配置8路独立隔离脉冲输入通道，支持5V-24V宽幅脉冲信号，兼容TTL/HTL/NAMUR标准传感器。

2. 单通道计数频率达1MHz，搭载32位硬件计数器，脉冲宽度识别精度＜100ns，计量精准度优异。

3. 兼容正交编码器（A/B/Z相），电机转速监测误差＜0.01%，适配旋转设备精准测速场景。

4. 无缝集成ABB Symphony Plus及Advant OCS系统，可直接接入原有DCS架构，无需额外适配。

5. 通道与背板间采用光电隔离设计，隔离电压≥2500VAC，强效抵御工业现场电磁与浪涌干扰。

6. 支持Profibus DP、Modbus RTU、DeviceNet多协议通信，灵活对接各类工控上位机与控制器。

7. 工作温度覆盖-25℃至60℃，相对湿度5%-95%（无冷凝），适配高低温、潮湿工业工况。

8. 内置μs级时间戳对齐技术，支持硬件触发同步采集，通道间同步误差≤1μs，数据一致性强。

9. 配备多色LED指示灯组，实时反馈模块运行状态、通道信号接收情况及故障告警，运维便捷。

10. 采用标准化DIN导轨安装，工业级阻燃外壳防护等级达IP20，防尘防油污，适配柜内安装。

11. 支持脉冲计数、频率测量、周期采集多模式，可精准计量转速、流量、位移等核心工业参数。

12. 内置过压、欠压及短路保护电路，自动切断故障回路，避免模块及前端设备损坏。

13. 支持固件在线升级与参数远程配置，无需拆卸模块即可优化功能，降低现场维护成本。

14. 采用可拆卸压线式终端块，接线牢固抗振动，支持预接线操作，提升现场安装效率。

15. 符合IEC61000电磁兼容标准及UL、CE认证，严苛遵循工业安全规范，适用于多行业自动化场景。

IMDSM04交响脉冲输入模块  英文资料：

IMDSM04 Symphonic Pulse Input Module Product Features (15 points)

1. Configure 8 independent isolated pulse input channels, support 5V-24V wide pulse signals, compatible with TTL/HTL/NAMUR standard sensors.

2. The single channel counting frequency reaches 1MHz, equipped with a 32-bit hardware counter, with a pulse width recognition accuracy of less than 100ns and excellent measurement accuracy.

3. Compatible with orthogonal encoders (A/B/Z phases), motor speed monitoring error<0.01%, suitable for precise speed measurement scenarios of rotating equipment.

4. Seamless integration of ABB Symphony Plus and Advant OCS systems, which can be directly connected to the original DCS architecture without additional adaptation.

5. The channel and backplane are designed with optoelectronic isolation, with an isolation voltage of ≥ 2500VAC, effectively resisting electromagnetic and surge interference in industrial sites.

6. Support Profibus DP, Modbus RTU, DeviceNet multi protocol communication, and flexibly interface with various industrial control upper computers and controllers.

7. The working temperature ranges from -25 ℃ to 60 ℃, with a relative humidity of 5% -95% (non condensing), suitable for high and low temperature, humid industrial conditions.

8. Built in μ s level timestamp alignment technology, supporting hardware triggered synchronous acquisition, with channel synchronization error ≤ 1 μ s, and strong data consistency.

9. Equipped with multi-color LED indicator lights, providing real-time feedback on module operation status, channel signal reception, and fault alarms, making operation and maintenance convenient.

10. Adopting standardized DIN rail installation, the industrial grade flame-retardant shell has a protection level of IP20, is dust-proof and oil proof, and is suitable for installation inside cabinets.

11. Supports multi-mode pulse counting, frequency measurement, and cycle acquisition, and can accurately measure core industrial parameters such as speed, flow rate, and displacement.

12. Built in overvoltage, undervoltage, and short-circuit protection circuits, automatically cutting off fault circuits to prevent damage to modules and front-end equipment.

13. Support firmware online upgrade and remote parameter configuration, optimize functions without disassembling modules, and reduce on-site maintenance costs.

14. Adopting a detachable crimping terminal block, the wiring is firm and vibration resistant, supporting pre wiring operations and improving on-site installation efficiency.

15. Compliant with IEC61000 electromagnetic compatibility standards and UL/CE certifications, strictly following industrial safety regulations, suitable for multi industry automation scenarios.
