1.产 品 资 料 介 绍：

IMDSI12数字输入模块产品特点（15条）

1. 配置12路独立数字输入通道，支持24/48/125VDC及120VAC多电压规格，适配场景更广泛。

2. 自带固定17毫秒去抖滤波器，可有效抑制机械开关抖动，保障信号采集稳定性。

3. 支持跳线手动配置工作电压与交直流模式，操作灵活，可适配不同现场信号需求。

4. 兼容ABB INFI 90开放式系统，可直接替代IMDSI02模块（跳线匹配后），升级无需改架构。

5. 通道与背板总线间采用光电隔离设计，隔离电压达500VAC，抵御现场电磁干扰。

6. 宽电压输入范围覆盖10-30VDC（直流模式），兼容主流工业传感器与开关信号。

7. 工作温度范围-20℃至60℃，耐受潮湿、粉尘工业环境，稳定性优于常规模块。

8. 搭配可拆卸终端块接线，支持预接线操作，现场安装与维护效率大幅提升。

9. 每路通道配备独立绿色LED指示灯，模块级故障指示灯同步提示，运维可视化。

10. 模块化紧凑设计，宽度适配标准DIN导轨安装，节省控制柜内安装空间。

11. 支持远程故障诊断，可精准识别通信异常、模块故障，便于快速定位问题。

12. 无需额外独立供电，通过系统背板获取工作电源，简化布线与供电架构。

13. 兼容EtherNet/IP、PROFIBUS-DP协议，可无缝对接罗克韦尔、西门子等主流控制器。

14. 外壳防护等级达IP20，绝缘机身设计，可承受轻微水滴飞溅，适配柜内安装工况。

15. 符合UL、CE、IEC 61131-2标准，严苛遵循工业安全规范，适用于多行业自动化场景。

IMDSI12数字输入模块   英文资料：

IMDSI12 Digital Input Module Product Features (15)

1. Configure 12 independent digital input channels, support 24/48/125VDC and 120VAC multi voltage specifications, and adapt to a wider range of scenarios.

2. Equipped with a fixed 17 millisecond debounce filter, it can effectively suppress mechanical switch jitter and ensure signal acquisition stability.

3. Support manual configuration of working voltage and AC/DC mode using jumper cables, with flexible operation and adaptability to different on-site signal requirements.

4. Compatible with ABB INFI 90 open system, can directly ｒｅｐｌａｃｅ IMDSI02 module (after jumper matching), upgrade without changing the architecture.

5. The channel and backplane bus are designed with optoelectronic isolation, with an isolation voltage of 500VAC, to resist on-site electromagnetic interference.

6. Wide voltage input range covering 10-30VDC (DC mode), compatible with mainstream industrial sensors and switch signals.

7. The working temperature range is -20 ℃ to 60 ℃, and it can withstand humid and dusty industrial environments with better stability than conventional modules.

8. Equipped with detachable terminal block wiring, supporting pre wiring operation, greatly improving on-site installation and maintenance efficiency.

9. Each channel is equipped with independent green LED indicator lights, synchronized module level fault indicator lights, and visualized operation and maintenance.

10. Modular and compact design, width compatible with standard DIN rail installation, saving installation space inside the control cabinet.

11. Support remote fault diagnosis, accurately identify communication abnormalities and module failures, and facilitate quick problem localization.

12. No need for additional independent power supply, obtain working power through the system backplane, simplify wiring and power supply architecture.

13. Compatible with EtherNet/IP and PROFIBUS-DP protocols, it can seamlessly integrate with mainstream controllers such as Rockwell and Siemens.

14. The shell protection level reaches IP20, the insulated body design can withstand slight water droplet splashes, and is suitable for installation conditions inside the cabinet.

15. Compliant with UL, CE, IEC 61131-2 standards, strictly following industrial safety regulations, suitable for multi industry automation scenarios.

IMDSI12数字输入模块   产品展示
