NMFC05多功能控制器模块

NMFC05多功能控制器模块

1.产 品 资 料 介 绍：

NMFC05多功能控制器模块

- 专为ABB Bailey Net 90/Infi 90系统设计，兼具逻辑控制与过程调节功能，适配多场景工业自动化需求。

- 防护等级达IP65，有效抵御灰尘与水汽侵入，可直接应用于潮湿、多尘的恶劣工业现场。

- 内置8路数字输入+8路数字输出通道，支持无源触点信号交互，适配各类传感器与执行器联动。

- 集成RS485与以太网双通信接口，兼容Modbus RTU/TCP协议，实现跨网络双向数据传输。

- 搭载专用工业微处理器，配备128KB RAM与512KB Flash存储，保障控制逻辑稳定运行与数据留存。

- 支持定时计数、逻辑联锁及过程闭环控制，可独立完成简单自动化流程，无需依赖上位机。

- 采用DC24V宽压供电设计，功耗低至3VA，适配工业现场不稳定供电环境，节能性突出。

- 机身尺寸紧凑（约10cm×15cm×5cm），重量仅0.4kg，可灵活嵌入标准控制柜及狭小安装空间。

- 具备协议转换能力，可实现ABB专有协议与通用工业协议互转，助力legacy系统与现代网络集成。

- 工作温度覆盖-20℃至+70℃，耐受振动、电磁干扰，适配电力、石化等行业复杂工况。

- 支持数据日志记录功能，实时存储输入输出状态与事件信息，为故障追溯与流程优化提供依据。

- 采用可插拔接线端子，安装拆卸便捷，搭配清晰标识，大幅缩短现场调试与维护时间。

- 通过CE、UL及RoHS认证，符合全球工业安全与环保标准，可广泛应用于国内外项目。

- 内置硬件级故障报警机制，异常时快速触发信号反馈，同时切断输出保护负载设备安全。

- 支持多模块协同工作，可通过扩展接口对接更多I/O模块，灵活拓展系统控制容量与功能。

NMFC05多功能控制器模块  英文资料：

NMFC05 Multi functional Controller Module

-Specially designed for ABB Bailey Net 90/Infi 90 systems, it combines logic control and process regulation functions, and is suitable for multi scenario industrial automation needs.

-The protection level reaches IP65, effectively resisting the intrusion of dust and water vapor, and can be directly applied to harsh industrial sites with high humidity and dust.

-Built in 8 digital inputs and 8 digital output channels, supporting passive contact signal interaction and adapting to various sensor and actuator linkage.

-Integrated RS485 and Ethernet dual communication interfaces, compatible with Modbus RTU/TCP protocol, enabling bidirectional data transmission across networks.

-Equipped with a dedicated industrial microprocessor, 128KB RAM and 512KB Flash storage, ensuring stable operation of control logic and data retention.

-Supports timed counting, logical interlocking, and process closed-loop control, and can independently complete simple automation processes without relying on the upper computer.

-Adopting a DC24V wide voltage power supply design, with a power consumption as low as 3VA, it is suitable for unstable power supply environments in industrial sites and has outstanding energy efficiency.

-The body size is compact (about 10cm × 15cm × 5cm), weighing only 0.4kg, and can be flexibly embedded into standard control cabinets and narrow installation spaces.

-Capable of protocol conversion, it can achieve the mutual conversion between ABB proprietary protocols and general industrial protocols, facilitating the integration of legacy systems with modern networks.

-The working temperature ranges from -20 ℃ to+70 ℃, with resistance to vibration and electromagnetic interference, and is suitable for complex working conditions in industries such as power and petrochemicals.

-Support data logging function, real-time storage of input and output status and event information, providing a basis for fault tracing and process optimization.

-Adopting pluggable terminal blocks, easy installation and disassembly, with clear labeling, greatly reducing on-site debugging and maintenance time.

-Through CE, UL, and RoHS certification, it meets global industrial safety and environmental standards and can be widely used in domestic and foreign projects.

-Built in hardware level fault alarm mechanism, quickly triggers signal feedback in case of abnormalities, and cuts off output to protect the safety of load devices.

-Support multi module collaborative work, can be connected to more I/O modules through expansion interfaces, and flexibly expand system control capacity and functions.

NMFC05多功能控制器模块   产品展示
