NTCF01终端单元

NTCF01终端单元

1.产 品 资 料 介 绍：

NTCF01终端单元

- 兼容工业级NTC热敏电阻信号，专注温度监测与数据转换，适配设备温控及过热保护场景。

- 支持8路NTC信号输入，兼容1kΩ-50kΩ标称电阻，适配不同精度测温需求，通用性强。

- 集成阻温转换电路，测温精度达±0.5℃，可精准捕捉微小温差变化，保障温控稳定性。

- 具备信号线性化处理功能，修正NTC非线性特性，输出标准4-20mA模拟信号对接DCS系统。

- 采用DC24V宽压供电，支持本地与远端双供电模式自动切换，切换时保持链路稳定无中断。

- 防护等级达IP65，防尘防水性能优异，可直接部署于潮湿、多尘的恶劣工业现场。

- 内置浪涌抑制与电磁屏蔽电路，抵御工业强干扰，确保温度信号传输精准无失真。

- 工作温度覆盖-40℃至+85℃，耐受高低温极端工况，适配户外及高温设备监测需求。

- 集成RS485通信接口，兼容Modbus RTU协议，支持与PLC、温控仪双向数据交互。

- 搭载双色LED指示灯，实时反馈电源、通信及通道故障状态，实现快速故障溯源。

- 采用紧凑型导轨安装设计，宽度仅22mm，可与其他工业模块密集布局，节省空间。

- 支持地址拨码设置，无需软件配置即可完成组网，大幅简化现场调试流程。

- 通过CE、UL及RoHS认证，符合IEC 60730安全标准，适配全球工业项目应用。

- 采用可插拔端子接线，搭配防脱落卡扣，接线牢固且维护时拆装便捷高效。

- 内置过热报警功能，温度超限时自动触发信号反馈，联动保护后端设备安全运行。

NTCF01终端单元 英文资料：

NTCF01 terminal unit

-Compatible with industrial grade NTC thermistor signals, focusing on temperature monitoring and data conversion, suitable for device temperature control and overheating protection scenarios.

-Supports 8 NTC signal inputs, compatible with 1k Ω -50k Ω nominal resistors, suitable for different precision temperature measurement requirements, and has strong universality.

-Integrated resistance temperature conversion circuit, with a temperature measurement accuracy of ± 0.5 ℃, can accurately capture small temperature differences and ensure temperature control stability.

-Equipped with signal linearization processing function, correcting NTC nonlinear characteristics, and outputting standard 4-20mA analog signals to interface with DCS system.

-Adopting DC24V wide voltage power supply, supporting automatic switching between local and remote dual power supply modes, maintaining stable and uninterrupted links during switching.

-The protection level reaches IP65, with excellent dust and waterproof performance, and can be directly deployed in harsh industrial sites with high humidity and dust.

-Built in surge suppression and electromagnetic shielding circuits to resist strong industrial interference and ensure accurate and distortion free transmission of temperature signals.

-The working temperature covers from -40 ℃ to+85 ℃, and can withstand extreme high and low temperature conditions, suitable for outdoor and high-temperature equipment monitoring needs.

-Integrated RS485 communication interface, compatible with Modbus RTU protocol, supports bidirectional data exchange with PLC and temperature controller.

-Equipped with dual color LED indicator lights, it provides real-time feedback on power, communication, and channel fault status, enabling rapid fault tracing.

-Adopting a compact guide rail installation design with a width of only 22mm, it can be densely arranged with other industrial modules, saving space.

-Support address dialing settings, network configuration can be completed without software, greatly simplifying the on-site debugging process.

-Certified by CE, UL, and RoHS, it complies with the IEC 60730 safety standard and is suitable for global industrial project applications.

-Adopting pluggable terminal wiring and equipped with anti ｄｒｏｐ buckles, the wiring is firm and easy to disassemble and install during maintenance.

-Built in overheating alarm function, automatically triggers signal feedback when temperature exceeds the limit, and links to protect the safe operation of backend equipment.
