NTAI02模拟输入终端单元

NTAI02模拟输入终端单元

1.产 品 资 料 介 绍：

NTAI02模拟输入终端单元

- 专为ABB工业控制系统设计，专注模拟量信号采集与传输，适配温度、压力等多类型传感器信号。

- 支持16路差分模拟输入通道，兼容4-20mA、0-10V标准信号，适配绝大多数工业模拟量传感器。

- 测量精度达±0.1%FS，采样率高达100Hz，保障微弱模拟信号精准捕获与实时传输。

- 集成高精度信号调理电路，具备信号滤波、放大功能，有效抑制噪声干扰，提升信号纯度。

- 采用DC24V额定供电，功耗低至2.5VA，适配工业现场集中供电系统，节能且稳定性强。

- 防护等级达IP54，防尘防飞溅水，可直接应用于车间等非防爆恶劣工业现场。

- 各输入通道具备独立电气隔离设计，隔离电压达1500V AC，规避通道间干扰与接地环路问题。

- 工作温度覆盖-25℃至+70℃，耐受低温、湿热工况，适配冬季工业生产防冻需求。

- 集成标准通信接口，兼容ABB专有协议，可无缝对接DCS系统实现数据上传与指令交互。

- 搭载通道状态指示灯，实时反馈信号采集状态，异常时快速定位故障通道，便于排查。

- 采用导轨式安装设计，结构紧凑不占空间，可与其他ABB模块协同布局，安装便捷。

- 支持在线校准功能，无需拆卸模块即可完成精度校准，大幅降低现场运维成本。

- 通过CE、IEC工业标准认证，符合全球工业安全规范，可广泛应用于电力、化工等行业。

- 采用螺丝端子接线，连接牢固防松动，搭配清晰通道标识，简化接线与调试流程。

- 内置过压、过流保护电路，有效防护传感器与模块核心部件，延长设备使用寿命。

NTAI02模拟输入终端单元 英文资料：

NTAI02 Analog Input Terminal Unit

-Specially designed for ABB industrial control systems, focusing on analog signal acquisition and transmission, adapting to various types of sensor signals such as temperature and pressure.

-Supports 16 differential analog input channels, compatible with 4-20mA and 0-10V standard signals, and suitable for the vast majority of industrial analog sensors.

-The measurement accuracy reaches ± 0.1% FS, with a sampling rate of up to 100Hz, ensuring accurate capture and real-time transmission of weak analog signals.

-Integrated high-precision signal conditioning circuit with signal filtering and amplification functions, effectively suppressing noise interference and improving signal purity.

-Adopting DC24V rated power supply, with a power consumption as low as 2.5VA, it is suitable for centralized power supply systems in industrial sites, energy-saving and highly stable.

-The protection level reaches IP54, dustproof and splash proof, and can be directly applied to non explosion proof and harsh industrial sites such as workshops.

-Each input channel has an independent electrical isolation design, with an isolation voltage of up to 1500V AC, to avoid interference between channels and grounding loop problems.

-The working temperature ranges from -25 ℃ to+70 ℃, and it can withstand low temperature, humid and hot working conditions, suitable for the anti freezing needs of industrial production in winter.

-Integrated standard communication interface, compatible with ABB proprietary protocols, can seamlessly integrate with DCS systems to achieve data uploading and instruction interaction.

-Equipped with channel status indicator lights, it provides real-time feedback on signal acquisition status, quickly locates faulty channels in case of abnormalities, and facilitates troubleshooting.

-Adopting a guide rail installation design, the structure is compact and does not take up space. It can be coordinated with other ABB modules for easy installation.

-Supporting online calibration function, precision calibration can be completed without disassembling the module, significantly reducing on-site operation and maintenance costs.

-Through CE and IEC industrial standard certification, it complies with global industrial safety regulations and can be widely used in industries such as power and chemical.

-Using screw terminal wiring, the connection is firm and anti loose, matched with clear channel identification, simplifying the wiring and debugging process.

-Built in overvoltage and overcurrent protection circuits effectively protect sensors and module core components, extending the service life of equipment.

NTAI02模拟输入终端单元  产品展示
