CI810B 3BSE020520R1 控制器模块

ABB CI810B 3BSE020520R1 控制器模块

1.产 品 资 料 介 绍：

中文资料：

ABB CI810B 3BSE020520R1 控制器模块 是 ABB 控制系统中用于工业自动化与过程控制的通信接口模块，常用于连接 S800 I/O 模块 与主控制器（如 AC 800M）之间的通信桥梁，支持 PROFIBUS DP 协议。

一、产品基本信息

二、功能与特点

1. PROFIBUS DP 接口

   • 模块作为从站接入 PROFIBUS 网络；

   • 允许 AC 800M 控制器通过 PROFIBUS 与远程 S800 I/O 模块通信。

2. 热插拔支持

   • 可在系统运行时更换，无需断电；

   • 提升系统可维护性与运行连续性。

3. 模块冗余支持

   • 可与另一 CI810B 进行冗余配置；

   • 在主模块故障时自动切换，保障通信不中断。

4. 集成诊断功能

   • 具备状态 LED 指示；

   • 支持系统内诊断与报警管理。

三、技术规格参数

英文资料：

The ABB CI810B 3BSE020520R1 controller module is a communication interface module used in ABB control systems for industrial automation and process control. It is commonly used as a communication bridge between S800 I/O modules and main controllers (such as AC 800M) and supports the PROFIBUS DP protocol.

1、 Basic Product Information

Project Content

Product Name: Communication Interface Module

Model CI810B

Order number 3BSE020520R1

Brand ABB

System Platform AC 800M Control System, S800 I/O Series

Communication protocol PROFIBUS DP Slave

2、 Function and Features

PROFIBUS DP interface

The module is connected to the PROFIBUS network as a slave station;

Allow AC 800M controller to communicate with remote S800 I/O module via PROFIBUS.

Hot swappable support

Can be replaced during system operation without power outage;

Improve system maintainability and operational continuity.

Module redundancy support

Can be redundantly configured with another CI810B;

Automatically switch in case of main module failure to ensure uninterrupted communication.

Integrated diagnostic function

Equipped with status LED indication;

Support system internal diagnosis and alarm management.

3、 Technical specifications and parameters

Project parameters

Communication type PROFIBUS DP (RS-485)

From station address range 0-125

Maximum baud rate of 12 Mbps

Supply voltage 24 V DC (powered through S800 I/O connector)

Power consumption is about 1.5 W

Interface type 9-pin SUB-D (DP interface)

Working temperature range -25 ° C to+70 ° C

Installation method: DIN rail, plug into S800 I/O base

Compatible with base modules TU810, TU812, TU830, TU833, etc

2.产      品      展      示
