1、 Product positioning and core values

The top hinge bracket of AMAT 0020-04129 serves as the original core structural component of Applied Materials semiconductor equipment, providing rigid support for the hinge system of the upper chamber door cover and maintenance port of the equipment. In the high-frequency operation scenarios of semiconductor manufacturing, it not only undertakes the basic functions of hinge load-bearing and opening and closing torque transmission, but also ensures the sealing and positioning accuracy of door closure through precision structural design. It is a key component to avoid particle pollution caused by mechanical looseness and reduce the risk of equipment shutdown.

2、 Core technical characteristics and process specifications

Technical dimension

Specific parameters and implementation details

Component Attributes

High precision mechanical fixed bracket, suitable for modular assembly requirements of semiconductor equipment hinge systems

Installation and positioning

The upper hinge integration area of the equipment is aligned coaxially with the rotation axis of the door cover, and the installation reference error is ≤ 0.1mm

Core functions

Hinge support, torque bearing, positioning calibration, capable of withstanding mechanical stress impact of ≥ 100000 opening and closing cycles

Material system

The main body is made of 304/316L stainless steel (chromium ≥ 18%, nickel ≥ 8%) or high-strength aluminum alloy, and some high-end models use titanium alloy composite structure

Surface technology

After chromium free passivation and electrolytic polishing treatment (Ra ≤ 0.8 μ m), salt spray testing for 500 hours without red rust, suitable for chemical corrosion environment in clean rooms

Fixed mechanism

Using a combination of coarse thread screws and serrated washers for fixation, coupled with hinge pins for coaxial positioning, anti vibration loosening design has passed 10-2000Hz vibration testing

3、 Scene adaptation and performance advantages

1. Adaptation to Semiconductor Core Scenarios

Process equipment chamber protection: used for fixing the hinge of the vacuum chamber door cover of lithography and etching equipment, ensuring the sealing fit between the door body and the chamber through precise axis positioning, avoiding process gas leakage and external particle invasion.

 AMAT Applied Materials 0020-04129顶部铰链支架 产品展示
