AMAT Applied Materials 0100-90941主板

AMAT Applied Materials 0100-90941主板

1.产 品 资 料 介 绍：

AMAT Applied Materials 0100-90941主板 英文资料：

1、 Highly integrated hardware architecture: supporting multi module collaboration of semiconductor devices

As the "control center" of semiconductor equipment, the 0100-90941 motherboard is designed with high integration hardware as its core, providing a unified control and data exchange platform for various functional modules of the equipment, ensuring stable system operation:

Multi core processors and computing power support

Equipped with an industrial grade multi-core processor (presumably Intel Atom or AMD Ryzen Embedded series), with a core count of ≥ 4 and a clock speed of ≥ 2.0GHz, it integrates high-performance GPU and hardware acceleration modules, with a computing power of over 100 GFLOPS. It can simultaneously run multiple tasks such as device control programs, process parameter calculations, and data collection analysis, with a response delay of ≤ 10ms, meeting the strict requirements for real-time and multi-threaded processing in 24-hour continuous operation of semiconductor devices, and avoiding process lag caused by insufficient computing power.

Rich interfaces and module compatibility

Integrate multiple types of standardized interfaces to cover the full scenario requirements of device control:

Data communication interface: 2 Gigabit Ethernet ports (supporting EtherNet/IP and Profinet protocols), 4 RS485 serial ports (used to connect sensors and actuators), and 1 USB 3.0 interface (used for local data export), achieving seamless data exchange with the factory MES system and equipment submodules;

Control signal interface: 8-channel digital input/output (DI/DO), 4-channel analog input (AI, supporting 4-20mA/0-10V signals), can be directly connected to relays, servo drives and other actuators without the need for additional IO expansion boards;

Storage interface: 2 SATA III interfaces (supporting SSD/HDD), 1 M.2 interface (supporting NVMe protocol high-speed storage), with a maximum storage capacity of 4TB, meeting the long-term storage needs of equipment process data and operation logs.

Layered power supply and stability optimization

Adopting a multi-channel independent power supply design, stable voltages (such as core voltage of 1.2V, memory voltage of 1.5V, interface voltage of 5V/12V) are provided for the processor, memory, and interface modules respectively, with a power supply accuracy of ± 1%; Equipped with redundant power interfaces and supporting dual power hot backup, the backup power can be switched within 50ms when the main power fails, ensuring that the core functions of the motherboard are not interrupted and avoiding equipment shutdown and wafer scrap caused by abnormal power supply.

AMAT Applied Materials 0100-90941主板  产品展示

 产品视频
