1、 Highly integrated interconnect architecture: building a collaborative center for controller modules

As the "hardware backbone" of semiconductor device controllers, the 0100-02492 controller backplane is based on multi module compatibility and high bandwidth interconnection, providing unified physical support and data exchange channels for internal CPU modules, IO modules, communication modules, etc., ensuring the coordinated operation of each module

Multi type module slot adaptation

Integrate 8-12 standardized slots (depending on configuration), compatible with the full range of AMAT controller functional modules:

Core computing slots: 2 high-performance CPU module slots (supporting AMAT dedicated multi-core processor modules), using PCIe 4.0 x16 bus interface, single slot bandwidth ≥ 32GB/s, meeting the controller's requirements for high-speed operation and real-time control of process data;

IO expansion slots: 4-6 IO module slots (supporting digital IO and analog IO modules), using PCIe 3.0 x4 bus, single slot supports 64 digital input/output or 32 analog input/output, can dock with peripheral devices such as sensors and actuators, realize process parameter acquisition and control instruction issuance;

Communication expansion slots: 2-4 communication module slots (supporting Ethernet, CANopen, Profinet modules), using PCIe 3.0 x2 bus, supporting multi protocol communication such as Gigabit Ethernet and industrial bus, can connect to factory MES system, remote operation and maintenance platform, realize equipment data exchange and remote control;

All slots are equipped with foolproof design (irregular interface+polarity positioning) to avoid hardware damage caused by module misplacement. The contact points of the slots are gold-plated (gold layer thickness ≥ 3 μ m) to reduce contact resistance (≤ 50m Ω), improve signal transmission stability and slot service life (insertion and removal times ≥ 1000 times).

Unified power supply and power distribution

Integrated multi-channel independent power supply circuit, supporting three voltage outputs of 12V DC, 5V DC, and 3.3V DC, with a total power supply of ≥ 300W:

12V DC channel (single channel current ≥ 20A): supplies power to high-power modules such as CPU modules and communication modules;

5V DC channel (single channel current ≥ 15A): supplies power to IO modules and sensor interface modules;

3.3V DC channel (single channel current ≥ 10A): provides power for low-power chips and signal processing circuits;

Each power supply channel is equipped with independent overcurrent protection (overcurrent threshold 1.2 times rated current), overvoltage protection (overvoltage threshold 1.1 times rated voltage), and voltage filtering circuit, with a power supply accuracy of ± 0.5%, ensuring stable and clean power supply for each module and avoiding module crashes or data loss caused by power supply fluctuations.
