AMAT Applied Materials 0190-09939主框架接口模块

AMAT Applied Materials 0190-09939主框架接口模块

1.产 品 资 料 介 绍：

AMAT Applied Materials 0190-09939主框架接口模块 英文资料：

1、 Full dimensional interface integration: building the main framework interconnection hub

As the "connection core" of the semiconductor equipment main framework, the 0190-09939 main framework interface module is designed with multiple types and highly integrated interfaces as its core, achieving seamless interconnection between the main framework and various internal functional modules (such as control units, driver modules, sensor clusters) and external systems of the equipment, breaking down data transmission barriers:

Exclusive interface coverage for the main framework

For the integration requirements of the main framework of semiconductor equipment, integrate dedicated interface types and adapt to the connection between the main framework and core modules:

Main controller interconnection interface: 2 high-speed backplane interfaces (supporting AMAT dedicated backplane protocol with a transmission rate of 2.5Gbps), which can directly interface with the device main controller (such as AMAT FAB300 automation controller), realizing high-speed interaction of instructions and data between the main framework and the control center, with a data transmission delay of ≤ 2ms, meeting the real-time control requirements of the main framework for each module;

Functional module expansion interface: 6 standard PCIe 4.0 slot interfaces (compatible with x1/x4/x8 channels), supporting access to driver modules (such as servo drives), data acquisition modules, RF control modules, etc., with a single slot bandwidth of ≥ 8GB/s, which can meet the data transmission requirements of high bandwidth modules and adapt to the functional expansion of the main framework;

Power distribution interface: 4-channel independent power interface (supporting 12V DC/24V DC dual voltage output, with a maximum current of 20A per channel), providing stable power supply for the connected functional modules, and also having power monitoring function to provide real-time feedback on the power supply status of each interface, ensuring the safety of module power supply.

Multi protocol communication interface integration

Covering the communication needs of semiconductor devices in all scenarios, achieving flexible interconnection between the main framework and internal and external systems:

Industrial Ethernet interface: 3 Gigabit Ethernet ports (supporting Profinet IRT, EtherNet/IP, Modbus TCP protocols) with a transmission rate of 1000Mbps, capable of connecting to factory MES systems and remote operation and maintenance platforms, supporting the main framework to upload device operation data (such as process parameters and fault information) to external systems, while receiving external control instructions, with a data packet loss rate of ≤ 0.001%;

Fieldbus interface: 5 RS485 serial ports (communication rate adjustable from 0-2Mbps, supporting Modbus RTU protocol), 2 CANopen bus interfaces, can interface with distributed sensors (such as temperature, pressure, position sensors) and actuators (such as solenoid valves, relays), RS485 interface can cascade up to 64 nodes, adapting to the control of distributed modules by the main framework;

Local operation and maintenance interface: 1 USB 3.0 interface (for local parameter configuration and log export), 1 VGA display interface (supporting connection to local display terminals), convenient for operation and maintenance personnel to debug parameters and monitor status next to the main framework, improving operation and maintenance convenience.
