P0917GZ FBM240输入输出模块

1.产 品 资 料 介 绍：

P0917GZ FBM240 输入输出模块 产品特点（15 条）

1. 专为 Foxboro I/A Series Compact200 系列 DCS 设计，8 入 8 出数字量 I/O 一体化模块。
2. 8 路独立隔离数字输入（电压监测）+8 路独立隔离继电器输出，通道间完全隔离。
3. 输出内置状态回读校验，实时比对指令与实际输出，异常自动标记通道故障。
4. 支持单模块独立 / 双模块冗余运行，冗余时现场 I/O 共用公共终端组件（TA）。
5. 继电器输出触点能力强：80–120VAC/10A、80–125VDC/5A、15–30VDC/5A。
6. 输入支持 15–60VDC 电压监测，适配工业现场各类开关与触点信号。
7. 通道间 / 对地高耐压隔离，抗电磁干扰强，适配强干扰工业环境。
8. 冗余 10Mbps/100Mbps 以太网通信，数据传输稳定、速率高。
9. 工业级宽温工作：-40℃~+60℃，适应化工、电力、冶金等恶劣工况。
10. 标准机箱插槽安装，结构紧凑，兼容 Foxboro 标准背板与底座。
11. 支持无工具热插拔，维护更换不影响系统连续运行。
12. 内置过流、短路保护，保护模块与现场执行器安全。
13. 故障安全设计，异常时输出可预置安全状态，保障工艺安全。
14. 适配公共终端组件（TA），支持本地 / 远程布线，现场部署灵活。
15. 长寿命、抗振动 / 冲击设计，满足流程工业连续生产高可靠要求。

P0917GZ FBM240输入输出模块 英文资料：

P0917GZ FBM240 Input/Output Module Product Features (15)

Specially designed for Foxboro I/A Series Compact200 series DCS, with an 8-in 8-out digital I/O integrated module.

8 independent isolated digital inputs (voltage monitoring)+8 independent isolated relay outputs, completely isolated between channels.

Output built-in status feedback verification, real-time comparison between instructions and actual output, automatic marking of channel faults for abnormalities.

Support single module independent/dual module redundant operation, with on-site I/O sharing common terminal components (TA) during redundancy.

Strong output contact capability of relays: 80-120VAC/10A, 80-125VDC/5A, 15-30VDC/5A.

Input supports 15-60VDC voltage monitoring and is compatible with various switch and contact signals in industrial sites.

High voltage isolation between channels/to ground, strong resistance to electromagnetic interference, suitable for strong interference industrial environments.

Redundant 10Mbps/100Mbps Ethernet communication ensures stable data transmission and high speed.

Industrial grade wide temperature operation: -40 ℃~+60 ℃, suitable for harsh working conditions such as chemical, power, metallurgy, etc.

Standard chassis slot installation, compact structure, compatible with Foxboro standard backplane and base.

Support tool free hot plugging, maintenance and replacement do not affect the continuous operation of the system.

Built in overcurrent and short-circuit protection, ensuring the safety of the protection module and on-site actuators.

Fault safety design, with pre-set safety status output in case of abnormalities to ensure process safety.

Adapt to public terminal components (TA), support local/remote cabling, and flexible on-site deployment.

Long lifespan, anti vibration/impact design, meeting the high reliability requirements of continuous production in process industries.

concluding summary

The P0917GZ FBM240 module integrates 8-in 8-out isolation, output read back verification, redundancy safety, and hot swappable maintenance. It is a highly reliable core component for digital I/O control in Foxboro DCS systems, suitable for the discrete signal acquisition and control needs of process industries such as petroleum, chemical, and power.

P0917GZ FBM240输入输出模块 产品展示
