IC697VAL318隔离模拟量输出模块

IC697VAL318隔离模拟量输出模块

1.产 品 资 料 介 绍：

一、核心定位与兼容性

1. 平台归属：Series 90‑70，兼容 RX7i PACSystem，6U VME 总线形态，占用 1 个机架插槽。
2. 核心用途：将 PLC 数字量转换为标准电压 / 电流信号，驱动调节阀、变频器、伺服放大器等，适配需外部供电的执行机构。
3. 供电要求：背板 + 5VDC，需搭配 IC697PWR724/748 等足额电源，支持热插拔与在线组态。
4. 手册依据：归属于 VAL3xx 系列官方手册（GFK‑2057），与 VAL304/308/314 同平台设计。

二、通道与隔离特性

5. 通道配置：8 路独立模拟输出，无分组共享，单模块满配 8 点，支持通道独立组态。
6. 隔离等级：通道间、通道与背板均 1500Vpk 电气隔离，彻底消除共模干扰与串扰，适配强干扰工业现场。
7. 输出模式：支持电压输出与电流回路输出，硬件跳线 + 软件组态双切换，兼容 Sink/Source 两种回路供电方式。

三、精度与输出范围

8. 转换精度：12 位 DAC，线性度 ±0.05% FS，零点 / 增益误差可软件校准，长期稳定性高。
9. 电压量程：0–5V、0–10V、±5V、±10V DC，负载阻抗≥10kΩ。
10. 电流量程：4–20mA、0–20mA，负载阻抗≤500Ω，支持回路供电与外部供电切换。
11. 响应时间：典型≤1ms，满足中高速闭环控制的实时性要求。

四、电气与诊断保护

12. 诊断功能：高级通道级诊断，支持输出开路、短路、过流、过载检测，故障状态可通过软件快速读取并触发报警。
13. 保护机制：内置过流 / 短路保护、反接保护，输出端 TVS 管防雷防浪涌，提升模块耐用性。
14. 功耗参数：+5VDC 典型 1.3A（含诊断电路），+15VDC/‑15VDC 辅助供电，需提前核对电源模块容量。

IC697VAL318隔离模拟量输出模块 英文资料：

IC697VAL318 is an 8-channel 12 bit fully isolated analog output module of GE Fanuc (now Emerson) Series 90-70 PLC platform VAL3xx series. It belongs to the same 8-channel specification as VAL308, with the core difference being the enhancement of output circuit power supply and diagnostic capabilities. It is designed specifically for industrial actuator drivers that require external circuit power supply (Sink/Source) and advanced fault diagnosis.

1、 Core positioning and compatibility

Platform ownership: Series 90-70, compatible with RX7i PACSystem, 6U VME bus configuration, occupying 1 rack slot.

Core application: Convert PLC digital signals into standard voltage/current signals, drive regulating valves, frequency converters, servo amplifiers, etc., and adapt to actuators that require external power supply.

Power requirements: Backboard+5VDC, requires sufficient power supply such as IC697PWR724/748, supports hot plugging and online configuration.

Manual basis: Belonging to the official manual of the VAL3xx series (GFK-2057), designed on the same platform as VAL304/308/314.

2、 Channel and isolation characteristics

Channel configuration: 8 independent analog outputs, no group sharing, single module fully equipped with 8 points, supporting channel independent configuration.

Isolation level: 1500Vpk electrical isolation between channels and between channels and backboards, completely eliminating common mode interference and crosstalk, suitable for strong interference industrial sites.

Output mode: Supports voltage output and current circuit output, dual switching of hardware jumper and software configuration, compatible with Sink/Source circuit power supply modes.

3、 Accuracy and output range

Conversion accuracy: 12 bit DAC, linearity ± 0.05% FS, zero/gain error can be calibrated by software, high long-term stability.

Voltage range: 0-5V, 0-10V, ± 5V, ± 10V DC, load impedance ≥ 10k Ω.

Current range: 4-20mA, 0-20mA, load impedance ≤ 500 Ω, supports switching between loop power supply and external power supply.

Response time: Typically ≤ 1ms, meeting the real-time requirements of medium and high-speed closed-loop control.

4、 Electrical and Diagnostic Protection

Diagnostic function: Advanced channel level diagnosis, supporting output open circuit, short circuit, overcurrent, and overload detection. The fault status can be quickly read through software and trigger an alarm.

Protection mechanism: Built in overcurrent/short circuit protection, reverse connection protection, output TVS tube lightning and surge protection, enhancing module durability.

Power consumption parameters:+5VDC, typical 1.3A (including diagnostic circuit),+15VDC/-15VDC auxiliary power supply. The capacity of the power module needs to be checked in advance.
