IC693APU301轴定位模块

 IC693APU301轴定位模块

1.产 品 资 料 介 绍：

1. 单轴独立控制：专用单轴伺服控制，不占用 PLC CPU 资源，自主完成定位运算
2. 双工作模式：支持标准模式（点位 / 速度控制）与从动模式（电子齿轮同步）
3. 最高 175kHz 反馈：兼容 AB 相编码器，单通道最高175kHz，适配高精度编码器
4. 多反馈类型：支持增量编码器、TEMPOSONICS 线性位移传感器等多种反馈
5. 可存储 10 套程序：内置非易失内存，可保存10 组运动程序，掉电不丢失
6. 8 路输入 4 路输出：自带 8 路通用输入、4 路输出，用于限位、原点、使能等逻辑
7. 双 24 针高密度接口：连接器 A 接伺服，连接器 B 接通用 I/O 与反馈，接线规范
8. 兼容 MCM001 接口：可通过 Motion Mate MCM001 模块连接数字伺服驱动器
9. 多模块扩展：嵌入式 CPU 最多支持 3 块，模块化 CPU（331+）最多支持8 块
10. LED 状态诊断：配备 STAT、OK、AXIS POS 等指示灯，实时监控运行与故障
11. 光电隔离保护：信号与内部电路全隔离，抗工业电磁干扰，保障稳定
12. 宽温工业设计：工作温度 **-25°C~+70°C**，适应严苛工业环境
13. 标准单槽安装：兼容 90-30 系列 PLC 底板，支持 CPU、扩展、远程基座安装
14. 软件便捷配置：通过 VersaPro、Logicmaster 90-30 软件完成参数与编程
15. 典型应用场景：包装机械、物料定位、飞剪、电子齿轮、单轴机器人、精密装配

结尾

 IC693APU301轴定位模块 产品英文

IC693APU301 is the Motion Mate Single Axis Positioning Module (APM) of GE Fanuc 90-30 series PLC, designed for high-precision motion control of servo/stepper motors. It supports independent positioning and electronic gear synchronization, and can achieve high-speed closed-loop control without the CPU main cycle. It is the core component for precision positioning, point motion, and synchronous tracking scenarios.

Single axis independent control: dedicated single axis servo control, does not occupy PLC CPU resources, independently completes positioning calculations

Dual working mode: supports standard mode (point/speed control) and driven mode (electronic gear synchronization)

Up to 175kHz feedback: compatible with AB phase encoders, single channel up to 175kHz, suitable for high-precision encoders

Multiple Feedback Types: Supports multiple feedback types such as incremental encoders, TEMPOSONICS linear displacement sensors, etc

Can store 10 sets of programs: Built in non-volatile memory, can store 10 sets of motion programs, not lost in case of power failure

8 inputs and 4 outputs: Comes with 8 universal inputs and 4 outputs, used for logic such as limit, origin, and enable

Dual 24 pin high-density interface: connector A is connected to servo, connector B is connected to universal I/O and feedback, with wiring specifications

Compatible with MCM001 interface: can connect digital servo drives through Motion Mate MCM001 module

Multi module expansion: Embedded CPUs can support up to 3 blocks, while modular CPUs (331+) can support up to 8 blocks

LED status diagnosis: equipped with STAT, OK, AXIS POS and other indicator lights, real-time monitoring of operation and faults

Optoelectronic isolation protection: The signal is fully isolated from the internal circuit, resistant to industrial electromagnetic interference, and ensures stability

Wide temperature industrial design: Operating temperature range of * * -25 ° C~+70 ° C * *, suitable for harsh industrial environments

Standard single slot installation: compatible with 90-30 series PLC baseboards, supporting CPU, expansion, and remote base installation

Convenient software configuration: Parameters and programming can be completed through VersaPro and Logicmaster 90-30 software

Typical application scenarios: packaging machinery, material positioning, flying shear, electronic gears, single axis robots, precision assembly

ending

IC693APU301 is an ideal choice for achieving high-performance single axis motion control in GE 90-30 PLC systems due to its independent computation, high-precision positioning, flexible synchronization, and stable reliability. It is widely adapted to the precision positioning and synchronization control requirements of automated production lines.

 IC693APU301轴定位模块  产品展示
